Valves and solenoid valves (ISO 15407-1) Series 7
Size: 18 mm (VDMA 24563-02), 26 mm (VDMA 24563-01)
5/2 – 5/3-way CC CO CP
VDMA 24563 (ISO 15407-1)
5/2 – 5/3-way CC CO CP
VDMA 24563 (ISO 15407-1)
The Series 7 solenoid valves with ISO 26 mm and 18 mm interface which have electropneumatic actuation and return are suitable for mounting on a sub-base.
For electrical actuation, 2 types of solenoid Series W and Series P (available with a wide range of voltages, on request).
For electrical actuation, 2 types of solenoid Series W and Series P (available with a wide range of voltages, on request).
The Series 7 solenoid valves with ISO 26 mm and 18 mm interface which have pneumatic actuation and return are suitable for mounting on a sub-base.
For the correct use of the valve, the pilot pressure must be the same or higher than the operating pressure.
General Data
| Construction | Balanced spool type |
| Valve functions | 5/2 – 5/3-way CC CO CP |
| Materials | AL body, spool base, polyamide endcovers, NBR seals |
| Mounting | By means of screws on the base |
| Ports | On sub-base |
| Operating temperature | 0° C min. +50° C max |
| Fluid | Filtered air (5 micron or less), without lubrication. If lubricated air is used, it is recommended to use ISOVG32 oil. Once applied the lubrication should never be interrupted. |
| Size | 26 mm 18 mm |
| Installation | In any position |
| Operating pressure | P. max 7 bar |
| Nominal pressure | 6 bar |
| Nominal flow | Qn Size 26 mm = 900 Nl/min Qn Size 18 mm = 450 Nl/min |
| Voltage | See Coding example |
| Voltage tolerance | ± 10% |
| Power consumption | 2W |
| Class of insulation | Class F |
| Protection | IP54 (IP65 with connector DIN 40050) |
Coding Example
| 7 | 5 | 1 | – | N | 1 | A | – | P16 | – | 15 | – | W | 2 | 3 |
| 7 | SERIES |
| 5 | NUMBER OF WAYS – POSITIONS 5 = 5/2 6 = 5/3 CC 7 = 5/3 CO 8 = 5/3 CP |
| 1 | SIZES 1 = 26 mm 2 = 18 mm |
| N | SUBBASE N = Sub-base with front outlets |
| 1 | PORTS 1 = G1/4 (Size 26 mm) 2 = G1/8 (Size 18 mm) |
| A | NUMBER OF SUBBASES A = 1 * B = 2 * C = 3 * D = 4 * E = 5 * F = 6 * G = 7 * H = 8 * K = 9 * L = 10 * M = 11 * N = 12 * P = 13 * R = 14 * S = 15 * |
| P16 | ACTUATION 33 = Pneumatic, bistable 36 = Pneumatic, monostable P11 = Electro-pneumatic, bistable P16 = Electro-pneumatic, monostable |
| 15 | SOLENOID INTERFACE 15 = 15×15 |
| W | SOLENOID TYPES W = Series W (24V – 48V DC only) P = Series P ** |
| 2 | CONNECTION 1 = Wire 300 mm (Series W, 24V DC only) ** 2 = 2 Pins (Series W, 24V – 48V DC) 5 = 2 Pins+earth (Series P) ** |
| 3 | SOLENOID VOLTAGE 3 = 24V DC 4 = 48V DC ** 6 = 110V DC (with Series P solenoids only) ** B = 24V 50/60 Hz (with Series P solenoids only) ** C = 48V 50/60 Hz (with Series P solenoids only) ** D = 110V 50/60 Hz (with Series P solenoids only) ** |
* Complete with the two end blocks
** On request
** On request
