Stainless steel mini-cylinders Series 94 and 95
Single-acting and double-acting, magnetic
Series 94: ø 16, 20, 25 mm
Series 95: ø 25 mm, cushioned
Series 94: ø 16, 20, 25 mm
Series 95: ø 25 mm, cushioned
The Series 94 and 95 cylinders can be used in critical applications in which a high corrosion resistance is required (for example off-shore, marine, food).
Their construction enables the replacement of all seals.
Series 95 is normally equipped with adjustable end-stroke cushioning by means of a screw on the end block.
In addition both Series 94 and 95 are equipped with a mechanical cushioning in order to make the impact of the piston less noisy as it reaches the end of the stroke.
General Data
| Construction | End blocks secured to the tube |
| Operation | Single-acting and double-acting |
| Design | ISO 6432 |
| Materials | End caps, rod and tube in stainless steel AISI 316, seals in NBR, plastic guiding element, NSF H1-certified lubricant |
| Mounting | Several types of cylinders clamps available |
| Strokes min – max | 10 ÷ 500 mm |
| Operating temperature | 0° – 80°C (with dry air -20°C) |
| Operating pressure | 1 ÷ 10 bar |
| Speed | 10 ÷ 1000 mm/sec (without load) |
| Fluid | Clean air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted. |
Coding Example
| 94 | N | 2 | A | 16 | A | 100 |
| 94 | SERIES 94 = magnetic 95 = magnetic, cushioned | |
| N | VERSION N = standard | |
| 2 | OPERATION 1 = single-acting, front spring 2 = double-acting 3 = double-acting, through-rod | PNEUMATIC SYMBOLS CS06 (S. 94) CD08 (S. 94) – CD09 (S. 95) CD12 (S. 94) – CD13 (S. 95) |
| A | MATERIALS A = stainless steel, seals in NBR V = stainless steel, all seals in FKM (150°C) | |
| 16 | BORE 16 = 16 mm 20 = 20 mm 25 = 25 mm | |
| A | TYPE OF DESIGN A = standard with locking ring for end cap Mod. V and piston rod lock nut Mod. U | |
| 100 | STROKE (see the table) | |
| = standard V = rod seal in FKM |
