Compact cylinders Tandem and Multi-position versions Series 32
Double-acting, magnetic
ø 25, 40, 63, 100 mm
ø 25, 40, 63, 100 mm
Thanks to their great compactness Series 32 cylinders, Tandem and Multi-position, are suitable to be installed within confined spaces and can be used with the same mounting elements of other standard cylinders ISO15552.
The Tandem version enables to obtain up to 2 times the thrust force of a normal cylinder (standard traction force), while the Multi-position version can obtain up to three positions with one cylinder only.
The Tandem version enables to obtain up to 2 times the thrust force of a normal cylinder (standard traction force), while the Multi-position version can obtain up to three positions with one cylinder only.
General Data
| Construction | Compact profile |
| Operation | Double-acting, magnetic |
| Material | Body and end-blocks = anodized AL rod = rolled stainless steel AISI 303 piston = anodized AL rod seal, OR end-block and piston seal = PU |
| Mounting | With threaded holes on the end blocks flange – feet – trunnion |
| Strokes min. and max. (1) Multi-position | Series 32F, 32M Ø25 = 5-300 mm (dimension x2) Series 32F, 32M Ø40 – 63 = 5-400 mm (dimension x2) Series 32F, 32M Ø100 = 5-500 mm (dimension x2) |
| Strokes min. and max. (1) Tandem | Series 32F, 32M Ø25 = 5-80 mm Series 32F, 32M Ø40 – 63 – 100 = 5-100 mm |
| Operating temperature | 0°C ÷ 80°C (with dry air -20°C) |
| Operating pressure | 1 ÷ 10 bar |
| Fluid | Clean air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted. |
| Operating speed | 10 ÷ 1000 mmsec (without load) |
(1) the minimum stroke for the use of the sensors is 10 mm.
Coding Example
| 32 | M | 2 | A | 040 | A | 050 | N | 2 |
| 32 | SERIES compact magnetic | |
| M | VERSION M = male rod thread, mounted with rod nut Mod. U F = female rod thread | |
| 2 | OPERATION 2 = double-acting | PNEUMATIC SYMBOLS CDPP |
| A | MATERIALS A = anodized aluminium profile, end blocks and piston PU seals (rod – OR end block and piston) | |
| 040 | BORE 025 = 25 mm 040 = 40 mm 063 = 63 mm 100 = 100 mm |
CD5T, CD6T, CD7T CD5T, CD6T, CD7T CD2T, CD3T, CD4T CD5T, CD6T, CD7T |
| A | CONSTRUCTION A = standard | |
| 050 | STROKE – Tandem stroke in mm – Multi-position X1mm/X2mm. Insert the strokes without the initial 0 (see application scheme) | |
| N | Tandem and Multi-position | |
| 2 | STAGES (for Tandem version only) 2 = 2 stages |
