Valves and solenoid valves Series 4
3/2, 5/2 and 5/3-way CC, CO
Ports: G1/8, G1/4, G3/8, G1/2
Ports: G1/8, G1/4, G3/8, G1/2
Series 4 solenoid valves have been designed in the 3/2, 5/2, 5/3 versions and with the following two devices of actuation:
– electropneumatically actuated with mechanical spring return
– electropneumatically actuated and return with external and internal air pressure supplySeries 4 valves are equipped with a manual override which allows a stable
operation and they are particularly suitable for mounting in arduous conditions.
– electropneumatically actuated with mechanical spring return
– electropneumatically actuated and return with external and internal air pressure supplySeries 4 valves are equipped with a manual override which allows a stable
operation and they are particularly suitable for mounting in arduous conditions.
All these valves can be operated by solenoids Series U, G A8 and H8.
Pneumatically actuated valves 3/2 NC become NO when the supply is on connection 3.
General Data
| Construction | Balanced spool type |
| Valve functions | 3/2 – 5/2 – 5/3-way CC, CO |
| Materials | AL body and subbases Stainless steel spool Technopolymer end cover NBR PU seals |
| Ports | G1/8 – G1/4 – G3/8 – G1/2 |
| Installation | In any position |
| Operating temperature | 0 ÷ 60°C (with dry air at -20°C) |
| Operating pressure | See table |
| Medium | Filtered air, without lubrication. If lubricated air is used, it is recommended to use ISOVG32 oil. Once applied the lubrication should never be interrupted. |
Coding Example
| 4 | 5 | 4 | – | 015 | – | 22 | IL | – | U7 | 7 |
| 4 | SERIES |
| 5 | NUMBER OF WAYS – POSITIONS 3 = 3/2 NC 4 = 3/2 NO 5 = 5/2 6 = 5/3 CC 7 = 5/3 CO |
| 4 | PORTS 2C = G1/2 2N = G1/2 (high flow) 3 = G3/8 4 = G1/4 8 = G1/8 |
| 015 | ACTUATION 011 = Double solenoid (horizontal solenoids) V11 = Double solenoid (vertical solenoids) for G1/4 port only E11 = Double solenoid external servo-command E15 = Single solenoid external servo-command 015 = Single solenoid, spring return (horizontal solenoids) V15 = Single solenoid, spring return (vertical solenoid) for G1/4 port only 016 = Single solenoid, pneumatic spring return (horizontal solenoid) V16 = Single solenoid, pneumatic spring return (vertical solenoid) for G1/4 port only 33 = Pneumatic pneumatic 34 = Pneumatic differential 35 = Pneumatic spring |
| 22 | SOLENOID INTERFACE 22 = Mech. sol. 22 x 22 50 = Mech. sol. 32 x 32 (only for 452C version) |
| IL | TYPE OF MANUAL OVERRIDE = Bistable, standard IL = Bistable, lever type (available on demand) IM = Monostable (available on demand) |
| U7 | ENCAPSULATING MATERIAL / SOLENOID DIMENSIONS A6 = PPS / 32 x 32 (only for 452C version) A8 = PPS / 30 x 30 G7 = PA / 22 x 22 G8 = PA / 30 x 30 (24 V DC only) G9 = PA / 22 x 58 H8 = PA 6 V0 / 30 x 30 U7 = PET / 22 x 22 |
| 7 | SOLENOID VOLTAGE |
