Positioning Feedback Cylinders ISO 15552 Series 6PF
Double-acting low friction, magnetic
Ø 50, 63, 80, 100, 125 mm
Ø 50, 63, 80, 100, 125 mm
Series 6PF pneumatic actuators are equipped with a potentiometric linear position transducer integrated inside the rod.
This type of cylinder allows, along the entire stroke, a constant control of the rod position which is read processing the change of the transducer internal resistance.
The pistons have been equipped with a permanent magnet which enables the use of external end-stroke sensors.
The dynamic seals are specific for low friction.
This type of cylinder allows, along the entire stroke, a constant control of the rod position which is read processing the change of the transducer internal resistance.
The pistons have been equipped with a permanent magnet which enables the use of external end-stroke sensors.
The dynamic seals are specific for low friction.
Thanks to the electrical connection, realized by means of an M12 male electric round connector positioned on the rear head, these cylinders fulfil the standards of IP67 protection class.
Series 6PF cylinders comply with the ISO 15552 standards and can be assembled with the entire range of standard accessories.
They are available with bores from 50mm to 125mm with standard strokes from 50mm to 1000mm with intervals of 50mm.
The sturdy design, the flexible installation and the high performance make Series 6PF suitable for use in applications with tensioning cylinders, positioning cylinders and filling, cutting and measuring systems.
General Data
| PNEUMATIC SECTION | |
| Construction | Inner tie-rods |
| Operation | Double-acting low friction, not cushioned |
| Mountings | Front and rear flange Foot mounts Front/rear/swivel/intermediate trunnion |
| Bores | 50, 63, 80, 100, 125 mm |
| Strokes min – max | 50 ÷ 1000 mm (step 50 mm) |
| Working temperature | 0°C ÷ 80°C (with dry air -20°C) |
| Working pressure | 0,1 ÷ 10 bar |
| Speed (min – max) | 5 ÷ 1000 mm/sec (no load) |
| Max acceleration | 10 m/sec² |
| Fluid | Filtered air class [5:4:4] according to ISO 8573-1. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted. |
| Linearity | 0,1% of the stroke |
| Repeatability [% FS] | 0,03% of the stroke |
| Resolution | Infinite |
| Hysteresis | < di 0,5 mm |
| Vibration test according EN 60068-2-6 | Severity level 3 |
| Shock test according EN 60068-2-27 | Severity level 2 |
| ELECTRICAL SECTION | |
| Electrical connection | Male connector M12 4 poles IP 67 (EN 60529) |
| Max input voltage | 40 V (stroke 50 mm) 60 V (strokes from 100 to 500 mm) |
| Max. recommended current | < di 0,1 µA |
| Electrical resistance | 5 kohm for strokes from 50 to 300 mm 10 kohm for strokes from 350 to 500 m |
| Tolerance on resistance | +/- 20% |
| Max dissipation (40°C) | 1 W for stroke 50 mm 2 W for stroke 100 mm 3 W for strokes from 150 to 500 mm |
| Suitable end-stroke sensors | CST-532 (3 wires) CST-562 (M8) |
| Suitable M12 connectors | CS-LF04HB (straight female connector 4 poles) CS-LR04HB (female connector 90° 4 poles) CS-LF05HB-D200 (female wired connector, 2 m, straight, 5 poles) ** CS-LF05HB-D500 (female wired connector, 5 m, straight, 5 poles) ** CS-LR05HB-D200 (female wired connector, 2 m, 90°, 5 poles) ** CS-LR05HB-D500 (female wired connector, 5 m, 90°, 5 poles) ** ** Do not collect pin n°5. |
Coding Example
| 6PF | 3 | P | 050 | A | 0200 |
| 6PF | SERIES | |
| 3 | OPERATION 3 = Double-acting low friction, no cushion | PNEUMATIC SYMBOLS CD22 |
| P | MATERIALS | |
| 050 | BORES 050 = 50 mm 063 = 63 mm 080 = 80 mm 100 = 100 mm 125 = 125 mm | |
| A | CONSTRUCTION A = Standard with rod nut RL = Cylinder with rod lock | |
| 0200 | STROKES | |
| VERSIONS = Standard P = PU rod seal V = FKM rod seal L = Without rod seal (rear supply only) * G = With brass rod scraper EX = ATEX ( _ _ _ ) = Wxtended piston rod _ _ _ mm * The possibility to order the cylinder without piston rod seal |
