SMT2001_Differential pressure transmitter
Service intended
The high performance pressure transmitter SMT2001 is suitable to measure liquid, gas, or steam flow as well as liquid level, density and pressure.
The key features include quick response, remote set-up using communications, self-diagnostics and optional status output for pressure high/low alarm.
Standard features
| Accuracy | ±0.05 % of calibrated span. ±0.075 % of calibrated span. |
| Range limits | 1 kPa ~ 3 MPa |
| Turn down | Adjustable up to 100:1 range ability |
| Temperature compensation | High sensitivity temperature sensor packaged in the sensor |
| Isolating diaphragm | 316L SS Hastelloy C 316L SS with gold plated 316L SS with FEP plated |
| Measurement medium | Gas, steam and liquid |
| Stability | 10 years stability 0.15 % of URL |
| Output | 4 ~ 20 mA with HART protocol |
| Degree of protection | EN60529/IEC529/IP66 EN60529/IEC529/IP67 |
