Precision regulators with manual override Series PR
Size 1 ports: G1/4
Size 2 ports: G1/4, G3/8
Size 2 ports: G1/4, G3/8
The Series PR precision pressure regulators are ideal for applications that require a precise and stable air pressure control.
The operating principle using multiple diaphragms allows the Series PR to react to even the smallest pressure variations that may occur during use.
The operating principle using multiple diaphragms allows the Series PR to react to even the smallest pressure variations that may occur during use.
General Data
| Construction | Compact, multi-diaphragm type |
| Materials | See the following page |
| Ports | Size 1: G1/4 Size 2: G1/4, G3/8 |
| Mounting | Vertical in-line, wall or panel mounting (in any position) |
| Working temperature | 0°C ÷ 50°C |
| Inlet pressure | 0.1 ÷ 12 bar |
| Outlet pressure | 0.05 ÷ 2 bar 0.05 ÷ 4 bar 0.05 ÷ 7 bar 0.05 ÷ 10 bar |
| Overpressure exhaust | With relieving (standard) |
| Nominal flow | See Flow diagrams |
| Fluid | Filtered and not lubricated compressed air according to DIN ISO 8573-1 Classes 1-3-2 |
| Hysteresis | 20mbar |
| Repeatability [% FS] | ±0.2% FS |
| Bleed air consumption | ≤ 5 l/min |
Coding Example
| PR | 1 | 04 | – | M | 07 |
| PR | SERIES |
| 1 | SIZE 1 = size 1 2 = size 2 |
| 04 | PORTS 04 = G1/4 38 = G3/8 (size 2 only) |
| M | TYPE OF ADJUSTMENT M = manual |
| 07 | OPERATING PRESSURE (1 bar = 14,5 psi): 02 = 0.05 ÷ 2 bar 04 = 0.05 ÷ 4 bar 07 = 0.05 ÷ 7 bar 00 = 0.05 ÷ 10 bar |
