Manifold pressure regulators Series MC
Ports G1/4
Modular
Modular
The manifold pressure regulators with ports G1/4 are available with a second pressure relieving and can be in-line or panel mounted.
General Data
| Construction | Compact modular, diaphragm type |
| Materials | Zama, NBR, technopolymer |
| Port | G1/4 |
| Weight | 0,320 Kg |
| Pressure gauge ports / outlet | G1/8 |
| Mounting | In-line, wall or panel mounting (in any position) |
| Working temperature | -5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature) |
| Finishing | Enamelled |
| Inlet pressure | 0 ÷ 16 bar |
| Outlet pressure | 0,5 ÷ 10 bar; 0,5 ÷ 2 bar; 0,5 ÷ 4 bar; 0,5 ÷ 7 bar |
| Secondary pressure (relieving) | Standard |
Coding Example
| MC | 1 | 04 | – | M | T | 0 | 2 |
| MC | SERIES |
| 1 | SIZE 1 = G1/4 |
| 04 | PORT 04 = G1/4 |
| M | MANIFOLD REGULATOR |
| T | OPERATING PRESSURE 0 = 0,5 ÷ 10 bar (standard) 1 = 0,5 ÷ 4 bar 2 = 0,5 ÷ 2 bar 7 = 0,5 ÷ 7 bar |
| 0 | CONSTRUCTION 0 = Self-relieving (standard) 1 = Non-relieving 5 = Precise relieving |
| 2 | PRESSURE GAUGE = Without pressure gauge (standard) 1 = With pressure gauge 0-2,5 with working pressure 0,5 ÷ 2 bar 2 = With pressure gauge 0-6 with working pressure 0,5 ÷ 4 bar 3 = With pressure gauge 0-10 with working pressure 0,5 ÷ 7 bar 4 = With pressure gauge 0-12 with working pressure 0,5 ÷ 10 bar T = Calibrated * B = Locked * |
* If the regulator is calibrated or locked, after the ports add the inlet pressure “■” and the outlet pressure “●”
INLET PRESSURE: ■ = Enter the SUPPLY pressure value
OUTLET PRESSURE: ● = Enter the OUTLET pressure value for the LOCKED regulator or the maximum value of the ADJUSTABLE pressure for the CALIBRATED regulator
Example of a calibrated regulator with Inlet Pressure = 6,3 bar and Outlet Pressure = 4,5 bar
Complete part number: MC104-MT03-6,3-4,5
* The pressure gauges are supplied disassembly
For size 1 pressure gauge mod. M043-P..
For size 2 pressure gauge Mod. M053-P..
