OPTIFLUX 2000
The OPTIFLUX 2000 is an electromagnetic flowmeter (EMF) for water and wastewater applications which has many drinking water approvals.
Technical data
| General technical data | |
|---|---|
| Measuring principle | Magnetic-inductive |
| Nominal widths | DN 25 to DN 300 |
| Accuracy | 0.5 % of the measured value |
| Medium temperature | Up to 90 °C |
| Process connection | PN 40 (DN 25 to DN 80), PN 16 (DN 100 to DN 150), PN 10 (DN 200 to DN 300) |
| Lining | PP, hard rubber |
| Ambient temperature | Up to 65 °C |
| Protection type | IP66/IP67, IP68 for remote version |
| Outputs | Analog output (4 to 20 mA) with HART and pulse/frequency/status |
| Display | LCD display, white backlight for displaying up to 3 measured values |
| Special features | Drinking water approval PP: ACS, DVWG, KTW, WRAS, NSF, KIWA |
