Manual retractable fittings
The primary applications areas of retractable fittings include pH measurements in closed-loop circuits or measurements in the supply and return lines for wastewater treatment plants. The retractable fitting can also be installed in container side walls, which allows removal of the sensor without needing to drain the container beforehand.
Technical data
| General technical data | |
|---|---|
| Process connection | Screw-in thread G ¾”; screw-in thread G 1″; clamp DN25 |
| Material | Stainless steel (1.4571) and FPM or PP and FPM |
| Max. temperature | -30 to +135 °C stainless steel; -10 to +60 °C PP |
| Pressure resistance | Up to 10 bar stainless steel; up to 6 bar PP |
| Immersion length (from process connection) | 48 to 135 mm |
| Features | Sensor exchange without interrupting the process; install sensors with an insertion length of 120 mm or 225 mm |
