Electronic vacuum/pressure switches Series SWCN
With digital display
High precision, easy to use
High precision, easy to use
Applications:
- Electronic vacuum/pressure switch for safety monitoring, optimization of cycle times or energy saving devices;
- It can be installed directly on the gripping point of a handling system;
- Setting of the limit vacuum value and continuous vacuum control;
- Perfectly suitable for customer needs.
Electric connection:
- The device is available with hardwired cable of 2 meters or can be supplied with M8 connector.
- Accessories and extensions have to be ordered separately. Codes can be found at the end of this section.
General Data
| Pressure/vacuum switch | Electronic with polycarbonate housing |
| Port | With external thread G1/8 and internal thread M5 |
| Display | 3 Digit display with membrane keypad for the values set up |
| LED | Integrated LED indicators for switching state |
| Electric connection | With M8 4-pole connector or pre-wired cable of 2 meters |
Coding Example
| SWCN | – | V01 | – | P3 | – | 2 |
| SWCN | SERIES |
| V01 | SET PRESSURE RANGE V01 = from -1 bar to 1 bar P10 = from 0 bar to 10 bar |
| P3 | TYPE OF ELECTRIC CONNECTION: P3 = 2 PNP outputs + 1 analog output 1 – 5 V DC (this version is available with 5-pole cable only) P4 = 2 PNP outputs P6 = 2 PNP outputs + 1 analog output 4-20 mA (this version is available with 5-pole cable only) |
| 2 | ELECTRIC CONNECTION 2 = Cable of 2 meters M = M8 4 pin connector |
