Directly operated proportional valves Series AP
2/2-way proportional valves, NC
Sizes: 16 – 22 mm
Sizes: 16 – 22 mm
Series AP directly operated 2/2-way proportional solenoid valves, NC, with nominal diameters range from 0,8 to 2,4 mm, can be used where an open loop flow control is required, with gas mixtures, to control free flows or blows, or emptying chambers using vacuum.
Series AP proportional valves have been manufactured to optimize and reduce friction and stick-slip effects.
The output flow is proportional to the control signal.
As they can work also in vacuum, a minimum working pressure is not required.
General Data
| Function | 2/2 NC |
| Operation | Proportional directly operated |
| Ports | M5 G1/8 With rear flanges With lower flanges |
| Hysteresis | Size 16mm: 12% FS Size 22mm: 10% FS |
| Repeatibility | Size 16mm: 7% FS Size 22mm: 7% FS |
| Operating temperature | 0 ÷ 60°C |
| Medium | Filtered compressed air, unlubricated, according to ISO 8573-1 class [3:4:3], inert gas. All the valves are suitable for use with oxygen. |
| Installation | Any position |
| Materials | Body = brass / PVDF (size 16mm only) Seals = NBR, FKM, EPDM |
| Nominal resistance | GP7 = 193 ohm GPH = 48 ohm U711 = 85 ohm U712 = 22 ohm |
| Rated current [mA] | GP7 = 125 mA GPH = 250 mA U711 = 271 mA U712 = 542 mA |
Coding Example
| AP | – | 7 | 2 | 1 | 1 | – | L | R | 2 | – | U | 7 | 11 | – | OX2 |
| AP | SERIES | ||
| 7 | BODY 6 = size 16mm |
7 = size 22mm | |
| 2 | NUMBER OF WAYS 2 = 2-way |
||
| 1 | VALVE FUNCTION 1 = NC |
||
| 1 | PORTS 0 = M5 (size 16mm only) 1 = G1/8 (size 22mm only) |
4 = with rear flanges (size 16mm only) 5 = with lower flanges |
L = male hose adaptor (for body in PVDF only, size 16mm) |
| L | ORIFICE D = Ø 0,8 mm (size 16mm only) F = Ø 1 mm |
H = Ø 1,2 mm L = Ø 1,6 mm |
N = Ø 2 mm (size 22mm only) Q = Ø 2,4 mm (size 22mm only) |
| R | SEAL MATERIAL R = NBR |
W = FKM | E = EPDM |
| 2 | BODY MATERIAL 2 = brass |
3 = PVDF (size 16mm only) | |
| U | ENCAPSULATING MATERIAL G = PA (size 16mm only) |
U = PET (size 22mm only) | |
| 7 | SOLENOID DIMENSIONS P = 16×26 DIN EN 175301-803-C (size 16mm only) |
7 = 22×22 DIN 43650 B (size 22mm only) | |
| 11 | SOLENOID VOLTAGE H = 12 V DC 3 W (size 16mm only) 7 = 24 V DC 3 W (size 16mm only) |
11 = 24 V DC 6,5 W (size 22mm only) 12 = 12 V DC 6,5 W (size 22mm only) |
|
| OX2 | USE WITH OXYGEN: = Not suitable for use with oxygen OX2 = for use with oxygen – cleanliness level according to ASTM G93-03 Standard Level B |
