VEGAPOINT 23
Compact capacitive limit switch with tube extension
For the detection of water-based liquids
Application area
From DK > 1.5, from thread ½”, universal connection G1″ for hygiene adapter, M12, valve plug, transistor output, IO-Link, wireless operation, Ex and hygiene approvals, tube version, up to 1 m
VEGAPOINT 23 is a limit switch with remote switching point for detection of water-based liquids. The optional universal connection for hygiene adapters ensures reduced installation effort and leaner stock keeping and perfectly meets the requirements for hygienic processes in the food, beverage and pharmaceutical industries. It can be used without adjustment in the application. With IO-Link, it offers continuous digital data transmission.
Your benefit
- Coloured 360° status display, adjustable
- Easy integration into control systems through IO-Link communication
- Low-cost limit switch with selectable switching point position / tube extension
Technical specifications
Measuring range – Distance
- – [Meter – Foot]
Process temperature
- -40 … 115 °C [°C – °F]
Process pressure
- -1 … 64 bar [Bar – kPa – psi]
Materials, wetted parts
- 316L
- PEEK
Threaded connection
- ≥ G½, ≥ ½ NPT
Hygenic fittings
- Clamp ≥ 2″, DN50 – DIN32676, ISO2852
- Clamp ≥ 1″ – DIN32676, ISO2852
- Clamp ≥ 1½” – DIN32676, ISO2852
- Slotted nut ≥ 1½”, ≥ DN40 – DIN 11851
- Slotted nut ≥ DN25 – DIN 11851
- Slotted nut ≥ DN32 – DIN 11851
Seal material
- EPDM
- FKM
Protection rating
- IP66/IP67
- IP69
Output
- Transistor (NPN/PNP)
- IO-Link
Ambient temperature
- -40 … 70 °C
Approvals
Scope
- ATEX / Europe
- IEC / worldwide
- KOSHA / Korea
- NEPSI / China
- UKR Sepro / Ukraine
- INMETRO / Brazil
- KTL Korea
- CSA / USA and Canada
- CCC
- IA
- UKEX
Explosion protection
- Dust ignition protection “t”
- Increased safety “e”
Foodstuffs/Pharma
- FDA
- EG1935/2004
Ship approval
- ABS
- BV
- CCS
- DNV
- LR
- NK
Overfill protection
- WHG
- VLAREM II
Display & adjustment
Adjustment
- Smartphone / Tablet / PC via Bluetooth
- PC, PACTware and DTM, IODD
Indication
- 360° status display
