VEGADIS 176
External display
External display for 4 … 20 mA/HART sensors, without external power supply for panel mounting
Application area
External display and adjustment module for panel mounting without external energy Application area The VEGADIS 176 is an external display and adjustment module without additional external energy. It is used for separate measured value indication of all standardized 4 … 20 mA circuits. Your benefit – Universal use through five-digit, scalable 17 mm display with backlight – Reliable function and various application possibilities thanks to a compact, robust housing with high protection rating in the front area – The low voltage drop of < 1 V allows the use in most 4 … 20 mA circuits Technical data Display:|;digital Voltage drop:|;< 1 V Signal: |;4 … 20 mA Mounting: |;panel mounting
Your benefit
- Reliable function and wide range of application thanks to compact, rugged housing with high protection rating
- Universal use through 5-digit, backlit, scalable 17 mm display
- The low voltage drop of <1 V allows use in most 4 … 20 mA circuits
Technical specifications
Protection rating
- IP20/IP65
Ambient temperature
- -10 … 60 °C
Signal input (specify)
- 4 … 20 mA/HART
Signal output (specify)
- 4 … 20 mA
Approvals
Scope
- ATEX / Europe
- FM / USA
- IEC / worldwide
Explosion protection
- Intrinsic safety “i”
Display & adjustment
Adjustment
- On-site adjustment
Indication
- Digital display
Documentation
Display instruments and adjustment
VEGADIS 176
