VEGADIS 82
External display and adjustment unit for 4 … 20 mA/HART sensors
External display and adjustment unit for 4 … 20 mA/HART sensors, optionally with Bluetooth
Application area
The VEGADIS 82 is suitable for measured value indication and adjustment of 4 … 20 mA sensors, optionally with HART protocol. The instrument can be looped in any position directly in the signal cable. It operates as pure display instrument in a 4 … 20 mA current loop. Optionally sensors with HART protocol can be operated. The instrument is particularly designed for VEGAPULS (C) 11, 21, 22, 23, 31 and VEGAWELL 52 sensors.
Your benefit
- Time and cost savings during the parameter adjustment on site with PLICSCOM
- Reliable and simple adjustment through clear text indication with graphic support
- Universal use through HART standard parameters
- Optional possibility of wireless operation via Bluetooth with smartphone/tablet/PC as well as magnetic pen operation in case of housing lid with inspection window
Technical specifications
Housing material
- Plastic
- Aluminium
- Stainless steel (precision casting)
Protection rating
- IP66/IP67
Ambient temperature
- -20 … 70 °C
Signal input (specify)
- 4 … 20 mA/HART
Approvals
Scope
- ATEX / Europe
- CSA / Canada
- FM / USA
- IEC / worldwide
- UKR Sepro / Ukraine
- CCOE / India
- UKEX
Explosion protection
- Intrinsic safety “i”
- Flameproof enclosure “d”
- Dust ignition protection “t”
Ship approval
- BV
- CCS
- DNV
Display & adjustment
Adjustment
- PLICSCOM
Indication
- Display/adjustment module PLICSCOM
Documentation
Display instruments and adjustment
VEGADIS 82
4 … 20 mA/HART
VEGADIS 82
4 … 20 mA
VEGADIS 82
4 … 20 mA/HART
