Valve islands, Multipole and Fieldbus Series 3 Plug-In
Plug-In system for Series 3 solenoid valves, G1/8 port.
Valve functions: 2×3/2, 5/2 and 5/3-way CO CC CP.
Multipole with a 25-pin Sub-D connector.
It can interface with all major serial communication protocols.
Valve functions: 2×3/2, 5/2 and 5/3-way CO CC CP.
Multipole with a 25-pin Sub-D connector.
It can interface with all major serial communication protocols.
The Multipole version of Series 3 Plug-In valve island can be easily installed thanks to the front position of the Sub-D connector. The accessories of the new connection system to the Series CX serial nets enable to handle up a multipole valve island by means of a Sub-D connector or through a node integrated in the island.
The modularity of the electric and pneumatic parts allows to install up to a maximum of 22 solenoids on 22 valve positions.The electric and pneumatic modules have 2- and 3-position modularity. To optimize the signals distribution, electric modules are available for monostable and bistable valves. The pneumatic modularity enables the creation of zones with differentiated pressure.
The modularity of the electric and pneumatic parts allows to install up to a maximum of 22 solenoids on 22 valve positions.The electric and pneumatic modules have 2- and 3-position modularity. To optimize the signals distribution, electric modules are available for monostable and bistable valves. The pneumatic modularity enables the creation of zones with differentiated pressure.
General Data
<tbody “=””>
| PNEUMATIC SECTION | |
| Valve construction | Spool type with seals |
| Valve functions | 5/2 – 5/3 CC – 5/3 CO – 5/3 CP – 2×3/2 NO – 2×3/2 NC – 1 3/2 NO + 1 3/2 NC |
| Materials | AL body, stainless steel spool, NBR seals, technopolymer |
| Mounting | Through-out holes in the manifold |
| Ports | Valve = G1/8 – manifold = G3/8 |
| Installation | In any position |
| Operating temperature | from 0°C to 60°C (with dry air at -20°C) |
| Nominal flow rate | Qn 700 Nl/min |
| Nominal diameter Ø [mm] | 7 mm |
| Fluid | Filtered air, class 7.4.4 according to ISO 8573-1-2010, without lubrication. If lubricated air is used, it is recommended to use ISO VG32 oil, and to never interrupt the lubrication. |
| ELECTRICAL SECTION – MULTIPOLE VERSION | |
| Type of connection | Multipole 25-pin male Sub-D |
| Supply voltage [Vdc] | 24 V DC +/- 10% |
| Max. number of solenoids | 22 on 22 valve positions |
| Signalling | Yellow LED |
| Duty cycle | ED 100% |
| Protection class | IP65 |
| ELECTRICAL SECTION – FIELDBUS VERSION | |
| General characteristics | See the section about the Series CX multi-serial module |
| Max. absorption | Digital outputs/analogic inputs and outputs 3A digital/analogic inputs 3 A |
| Voltage tolerances | Logic supply 24 V DC +/- 10% power supply 24 V DC +/- 10% |
