Thermowells

Thermowells are used for replacement of the RTD temperature probes without emptying the system and/or pressure resistance. Shorter thermowells are mostly screwed into T-pieces while longer design types are screwed into special welded sockets or welded directly in the pipe wall.

Categories: Accessories, Temperature, Temperature sensor for heat meters

Technical data
Downloads

Technical data

general technical data
Protection tube	Stainless steel 1.4571, stainless steel 1.4435, brass
Insertion length	35 to 400 mm (stainless steel), 35 to 120 mm (brass)
Special features	RTD temperature probes can be replaced without emptying the system, MID-compliant with identification marking
Option	Available with inspection certificate 3.1, internal thread G 1/4 or M10 × 1, seal option
Process connection	Screw connection G 1/4, 1/2, 3/4, 3/8, weld-in sleeve according to AGFW

general technical data

Protection tube

Stainless steel 1.4571, stainless steel 1.4435, brass

Insertion length

35 to 400 mm (stainless steel), 35 to 120 mm (brass)

Special features

RTD temperature probes can be replaced without emptying the system, MID-compliant with identification marking

Option

Available with inspection certificate 3.1, internal thread G 1/4 or M10 × 1, seal option

Process connection

Screw connection G 1/4, 1/2, 3/4, 3/8, weld-in sleeve according to AGFW
