Roundline cylinders Series 27
Double-acting, magnetic
ø 20, 25, 32, 40, 50, 63 mm
ø 20, 25, 32, 40, 50, 63 mm
Series 27 has been designed to reduce the cylinders sizes as much as possible. These cylinders have been constructed with clean lines using stainless steel for both the tube and the rod and Aluminium for the end-blocks.
The choice of material and other design features have allowed to create a range of versatile and reliable cylinders.
The precise method of securing the tube to the end block ensures that all the parts are perfectly aligned.
Mechanical cushioning has been fitted on these cylinders in order to reduce noise produced by the piston impact on the end-blocks.
Cylinders Series 27 are suitable for assembling with magnetic sensors.
Various mounting bracket accessories enable the cylinders to be fitted to suit the requirements of a particular application.
General Data
| Type of construction | Flanged |
| Operation | Double acting |
| Materials | Rod: Ø20 – 25 stainless steel AISI 303 – Ø32 ÷ 63 stainless steel AISI 420B tube: INOX AISI 304 piston and rod seals = PU |
| Mounting | Feet – trunnion – steel bar – pins |
| Strokes (min-max) | All diameters 10 – 1000 mm |
| Bores | Ø 20, 25, 32, 40, 50, 63 mm |
| Operating temperature | 0°C ÷ 80°C (with dry air – 20°C) |
| Operating pressure | 1 ÷ 10 bar |
| Speed | 10 ÷ 1000 mm/sec (no load) |
| Fluid | Filtered air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted. |
Coding Example
| 27 | M | 2 | A | 20 | A | 0050 |
| 27 | SERIES | |
| M | VERSION M = rear endblock with trunnion and upper round port for ø 20-25-32-40 T = rear endblock with rear round port for ø 20-25-32-40 U = rear endblock with upper round port for ø 20-25-32-40-50-63 | |
| 2 | OPERATION 2 = double-acting | PNEUMATIC SYMBOL CD08 |
| A | MATERIALS A = rolled stainless steel rod – stainless steel tube | |
| 20 | BORE 20 = 20 mm – 25 = 25 mm – 32 = 32 mm – 40 = 40 mm – 50 = 50 mm – 63 = 63 mm | |
| A | TYPE OF DESIGN A = standard | |
| 0050 | STROKE (see the table) |
