Pressure booster Series BPA
Sizes: 40, 63, 100
This pressure booster has a pressure ratio of 2:1 that increases outlet pressure by up to 20 bar.
It operates automatically when needed to generate a constant pressure increase while its mechanical design guarantees quick and easy installation, minimises heat generation and improves machine safety.
Two versions are available, with or without an integrated regulator that allows to adjust the desired outlet pressure and enables the efficient management of energy consumption.
It operates automatically when needed to generate a constant pressure increase while its mechanical design guarantees quick and easy installation, minimises heat generation and improves machine safety.
Two versions are available, with or without an integrated regulator that allows to adjust the desired outlet pressure and enables the efficient management of energy consumption.
It offers a compact, functional design with rapid filling times that makes the Series BPA ideal for applications where high pressure is only needed at specific points in the pneumatic circuit such as woodworking, marble and glass processing or with testing and assembly machines.
General Data
| Sizes | 40 | 63 | 100 |
| Multiplication Ratio (Pout:Pin) | 2:1 | ||
| Inlet pressure | 2-10 bar | 2-8 bar | |
| Operating temperature | 0-50 °C | ||
| Mounting position | Any position | ||
| Flow rate (p.in = p.out = 5 bar) | 250 l/min ANR | 700 l/min ANR | 1200 l/min ANR |
| Pneumatic connection | G1/4” | G3/8” | G1/2” |
| Weight (standard version) | 0,85 Kg | 3,00 Kg | 5,90 Kg |
| Weight (version with regulator) | 1,06 Kg | 3.21 Kg | 6,11 Kg |
| Materials | Body and barrels: Aluminium – Rod: steel – Seals NBR | Body and end caps: Aluminium – Barrels: extruded aluminium – Rod: steel – Seals: NBR | Body and end caps: Aluminium – Barrels: extruded aluminium – Rod: steel – Seals NBR |
Coding Example
| BPA | – | 040 | – | R1 |
| BPA | SERIES |
| 040 | SIZES 40 63 100 |
| R1 | REGULATOR = Without regulator – MP01 R1 = With regulator (P.IN 2-8bar – P.OUT 0-10bar) – MP02 R2 = With regulator (P.IN 2-10bar – P.OUT 0-16bar) – MP02 |
