JUMO I/O system digital output module 16-channel
As part of the JUMO I/O system, the module can provide 16 digital outputs for all models of the JUMO variTRON automation system. It can also be operated with other PLCs if they support the JUMO system bus. To facilitate a quick startup, the slim DIN rail device offers standard PUSH IN terminal strips and connects to the operating voltage and system bus simply by plugging the modules together.
Technical data
| General technical data | |
|---|---|
| Channels | 16 |
| Connection | Terminal strips with PUSH IN technology on the front |
| Special features | Switching statuses are visualized with LEDs; automatic configuration after replacement of the module insert (Plug and Play); quick wiring of operating voltage and system bus provided by simply plugging the modules together; space-saving design type; operation with JUMO variTRON, other PLCs (via JUMO system bus), and in combination with earlier JUMO I/O modules (7050xx) possible; increased vibration and shock resistance through optional connection rails |
| Voltage supply | DC 24 V +25/-20 %, supply via central processing unit with system module 705171 (JUMO variTRON 500) or communication module 3-channel 705163 (JUMO variTRON 300, JUMO variTRON 500 touch, third-party products) |
| Housing | Plastic housing for DIN-rail mounting in the control cabinet |
| Protection type | IP20 |
| Approvals | DNV, UL |
| Ambient temperature range | -20 to +55 °C |
| Dimensions (W × H × D) | 12 × 106.7 × 101 mm (without connection elements) |
