GRIPfit push-in Fittings Series 7000 – Inch
GRIPfit inch is the latest generation of push-in fittings developed to cover and satisfy the needs of industrial automation.
Made with high-performance materials, this new range of fittings is equipped with a flexible stainless steel gripping ring to facilitate the connection and disconnection of most semi-rigid tubes, limiting the effects of tube marking and guaranteeing a robust and reliable tightening on the whole surface of the tube.
GRIPfit inch is ideal for vacuum and low pressures both in static and dynamic applications, thanks to shaped sealing technology.
The materials used comply with the main standards and directives and have been designed to meet and adapt perfectly to the specific application requirements of each sector.
Reliable connection, compact dimensions and easy installation in confined spaces are only some of the features that make this new range of fittings an innovative solution for many applications.
General Data
| Applicable fluid | Compressed air |
| Operating pressure | 29.5″ Hg vacuum up to 150 psi |
| Operating temperature | 32°F to 140°F |
| Hose materials used | Nylon 11 or 12 Polyurethane 85 or 95 durometer |
| Material | Body: PBT | Seals: NBR (silicone free) Threaded bodies: nickel plated brass | Push button and backing ring: POM Gripping: stainless steel | Collar: zinc |
| Tube sizes | Standard sizes: 5/32″, 1/4″, 5/16″, 3/8″ and 1/2″ |
| Thread sizes | Standard sizes: 10-32 UNF, 1/8”, 1/4”, 3/8”, 1/2” NPTF |
