Filters, coalescing filters and activated carbon filters Series N
Ports: G1/8, G1/4
Series N filters are available with G1/8 and G1/4 gas ports.
The models are available with 3 different filtering elements: 25, 5, 0,01µm and actived carbon.The version with semi-automatic manual drain is equipped with a transparent bowl that makes the monitoring of the condensate level very easy.The version with metal bowl is particularly suitable for applications subject to impacts or in the presence of aggressive agents that could damage the PA12 bowl.
The models are available with 3 different filtering elements: 25, 5, 0,01µm and actived carbon.The version with semi-automatic manual drain is equipped with a transparent bowl that makes the monitoring of the condensate level very easy.The version with metal bowl is particularly suitable for applications subject to impacts or in the presence of aggressive agents that could damage the PA12 bowl.
General Data
| Construction | HDPE, coalescing and actived carbon filtering element |
| Materials | Brass, transparent PA12 or nickel-plated brass, NBR |
| Ports | G1/8 – G1/4 |
| Max condensate capacity | 11 cm³ (bowl size = 1) 28 cm³ (bowl size = 2) |
| Weight | 0,220 kg |
| Mounting | Vertical, inline |
| Working temperature | -5°C ÷ 50°C at 10 bar (with the dew point of the fluid lower than 2°C at the min. working temperature) |
| Quality of delivered air according to ISO 8573-1:2010 | Class [7:8:4] with 25 µm filtering element Class [6:8:4] with 5 µm filtering element Class [1:8:1] with 0,01 µm filtering element Classe [1:7:1] with actived carbon filtering element |
| Draining of condensate | See the coding example |
| Fluid | Compressed air |
| Pre-filtering | It is recommended to use a filter with residual oil of 0,01mg/m³ |
Coding Example
| N | 2 | 04 | – | F | 0 | 0 | – |
| N | SERIES |
| 2 | SIZE 1 = Small bowl (11 cm³) 2 = Normal bowl (28 cm³) |
| 04 | PORTS 08 = G1/8 04 = G1/4 |
| F | FILTER |
| 0 | FILTERING ELEMENT 0 = 25μm (standard) 1 = 5μm B = 0,01μm CA = Actived carbon (without drain, only closed bowl size 2) |
| 0 | DRAINING OF CONDENSATE 0 = Semi-automatic manual drain 4 = Depressurisation (normal bowl only) 5 = Protected depressurisation (normal bowl only) 8 = No drain, direct G1/8 exhaust 9 = Closed bowl (OX1 version) |
| BOWL MATERIAL = Transparent PA12 (standard) TM = Nickel-plated brass (only in the small size with semi-automatic manual drain or without drain, port 1/8) |
