Compensating cables/thermal cables
The temperature measurement using thermocouples requires the temperature of the cold junction to be measured in addition to the thermoelectric voltage. The cold junction temperature is acquired at the connection terminals of the evaluation electronics.
Technical data
| general technical data | |
|---|---|
| Temperature | -20 to +350 °C, -50 to +180 °C, 5 to 105 °C |
| Compensating cable | Sheath made from PTFE, silicone, PVC, or glass fiber, steel or stainless steel braiding |
| Features | Up to 200 °C the same thermoelectric features as the thermocouples |
| Standard | DIN EN 60584-3, DIN 43713 |
| Application | Single and double thermocouples |
| Environmental influences | Dry and humid locations |
