Basic ejectors Series VEBL
Basic ejectors in technopolymer without moving parts, based on the Venturi principle.
Different sizes available, with internal nozzle from 0,5 to 2,5 mm and with suction rate from 8 to 207 l/min.
Different sizes available, with internal nozzle from 0,5 to 2,5 mm and with suction rate from 8 to 207 l/min.
Series VEBL basic ejectors are universal ejectors made in technopolymer suitable for several industrial applications such as:
- Industrial robotics in most sectors
- Wood industry
- Packaging industry
- Food industry
General Data
| Description | Basic ejector |
| Materials | Body in technopolymer Silencier in technopolymer Internal nozzle in brass |
Coding Example
| VEBL | – | 10H | – | T2 |
| VEBL | SERIES VEBL = vacuum ejector |
| 10H | NOZZLE DIAMETER 05H = 0,5 mm 07H = 0,7 mm 10H = 1 mm 15H = 1,5 mm 20H = 2 mm 25H = 2,5 mm |
| T2 | TYPE OF CONNECThttps://vlmsolutions.com.my/wp-content/uploads/2025/09/Series_VEBL_VEDL_ejectors.pdfION (ON SUPPLY SIDE) T1 = plier – tube Ø4 T2 = plier – tube Ø6 T3 = plier – tube Ø8 |
