AMF601 Series
The AMF601 Series is a sanitary-type electromagnetic flowmeter ideal for conductive liquids. It comes in sizes from 10-80 mm.
The AMF601 is widely used for drink water, milk, food & beverage juice and many other industrial fluids.
AMF601 Series electromagnetic flowmeter can be used in compact or remote model with AMC Series converter of electromagnetic flowmeter.
Features
- Light and compact version
- Flow velocity range: 0-12 m/s, precise in low flow applications
- IDF Tri-Clamp or Union screw Connection
- Excellent for high pressure application
- Protection class: IP68 available; sensor submersible
- FEP liner is suitable for vacuum tube
- High accuracy of +/-0.4% value of reading (or +/-0.2% value of reading)
- With Forward / Reverse flowrate measurement function
Specification
| Size | : | 10,15, 20, 25, 32, 40, 50, 65, 80 mm |
| : | 3/8″, 1/2″, 3/4″, 1″, 1-1/4″, | |
| 1-1/2″, 2″, 2-1/2″, 3″ | ||
| Measuring Range | : | Velocity 0-0.25 m/s Min. |
| 0-12 m/s Max. | ||
| Material | ||
| Tube & Connection | : | Stainless Steel 304 (Standard) |
| : | Stainless Steel 316L (Option) | |
| Coil Housing | : | Stainless Steel 304 (Standard) |
| : | Stainless Steel 316L (Option) | |
| Liner | : | FEP |
| Electrode | : | Stainless Steel 316L |
| : | Hastelloy B | |
| : | Hastelloy C | |
| : | Titanium | |
| : | Tantalum | |
| : | Tungsten Carbide | |
| : | Platinum | |
| Conductivity | : | More than 5 μS/cm |
| Cable Entry | : | Standard: M20 Option: 1/2″ NPTF |
| Ambient Temperature | : | -25 ~ 60 °C |
| Process Connection | : | IDF Tri-Clamp |
| : | Union Screw | |
| Grounding Resistance | : | Must be less than 10 Ω |
| Accuracy | : | +/-0.5% reading (Velocity≥0.5 m/s) |
| : | +/-0.2% reading | |
| (Suitable for AMC3200 / 3200E converter) | ||
| : | +/-0.0025 m/s (Velocity<0.5 m/s) | |
| Temperature | : | -40 ~ 140 °C |
| Max. Pressure | : | 10 kgf/cm2 (Standard) |
| : | 40 kgf/cm2 (Option) | |
| Protection Class | : | Junction box IP67, Body IP68 |
| : | IP68 (Submersible) | |
| Explosion Proof | : | Ex d ia [ia] q llC T6 |
| (with AMC3200, AMC3200DF only) |
