AMF900 Series
The AMF900 Series is a flange-type electromagnetic flowmeter ideal for conductive liquids. It comes in sizes from 10A to 2000 mm.
AMF900 is widely used for sewage, industrial waste, chemical, solvent, food & beverage, pulp & paper and many other industrial fluids.
AMF900 Series electromagnetic flowmeter can be used in compact or remote model with AMC Series converter of electromagnetic flowmeter.
Features
- Various liners and electrodes satisfy most industrial applications
- Flow Velocity range: 0-12 m/s, precise in low flow applications
- It comes in any flanges such as, ANSI, DIN, JIS etc.
- Excellent for high pressure application
- Protection class: IP68 available; sensor submersible
- FEP Liner is suitable for vacuum tube
- High accuracy of +/-0.4% value of reading (or +/-0.2% value of reading)
- With Forward / Reverse flowrate measurement function
- It has an electrode cleaning function
Specification
| Size | : | 10A, 10, 15, 20, 25, 32, 40, 50, 65, 80, |
| 100, 125, 150, 200, 250, 300, 350, 400, | ||
| 450, 500, 600, 700, 800, 900, 1000, | ||
| 1200, 1400, 1600, 1800, 2000 mm | ||
| Measuring Range | : | Velocity 0-0.25 m/s Min. |
| 0-12 m/s Max. | ||
| Material | ||
| Measuring Tube | : | Stainless Steel 304 |
| Flange | : | Carbon Steel (Standard) |
| : | Stainless Steel 304 (Option) | |
| : | Stainless Steel 316, 316L (Option) | |
| Coil Housing | : | Carbon Steel (Standard) |
| : | Stainless Steel 304 (Option) | |
| : | Stainless Steel 316, 316L (Option) | |
| Liner | : | Polyurethane (25-400 mm) |
| : | Neoprene (100-2000 mm) | |
| : | FEP (10A-300 mm) | |
| : | PTFE (25-2000 mm) | |
| : | PFA (10A-300 mm) | |
| Protection Class | : | Junction box IP67, Body IP68 |
| : | IP68 (Submersible) | |
| Conductivity | : | More than 5 μS/cm |
| Explosion Proof | : | Ex d ia [ia] q llC T6 |
| (with AMC3200, AMC3200DF only) | ||
| Cable Entry | Standard: M20 Option: 1/2″ NPTF |
| Electrode & Grounding | : | Stainless Steel 316L |
| : | Hastelloy B | |
| : | Hastelloy C | |
| : | Titanium | |
| : | Tantalum | |
| : | Platinum | |
| : | Tungsten Carbide | |
| Grounding Electrode | : | DN10A / 10: use Grounding Ring * 1 pc |
| : | DN15-2000: 3 Electrodes | |
| Process Connection | : | Flange |
| Flange Type | : | JIS 10K / JIS 20K / JIS 40K |
| ANSI 150# / ANSI 300# / ANSI 600# | ||
| DIN PN10 / PN16 / PN25 / PN40 | ||
| Grounding Resistance | : | Must be less than 10 Ω |
| Accuracy | : | +/-0.4% of reading (Velocity≥0.5 m/s) |
| : | +/-0.0025 m/s (Velocity<0.5 m/s) | |
| : | +/-0.2% of reading | |
| (Suitable for AMC3200 / 3200E converter) | ||
| Temperature | : | -20~70 °C(Polyurethane,PU) |
| : | -20~70 °C(Neoprene) | |
| : | -40~120 °C(PTFE 1″-10″,FEP/PFA 3/8″-12″) | |
| : | -40~150 °C(PTFE 1″-6″,FEP/PFA 3/8″-12″) | |
| : | -40~180 °C(PFA 3/8″-12″) | |
| Ambient Temperature | : | -25~60 °C |
| Max. Pressure | : | 350 kgf/cm2 |
