AHT530 Series
The AHT530 Series is a battery-powered, hand-held unit designed to configure, calibrate and troubleshoot to smart transmitter either remotely or nearby.
AHT530 allows you to establish communication with a Hart field instrument over the existing 4-20 mA DC lines, covering the five process variables of flow, pressure, temperature and level, control valve etc.
Features
- Common to most smart field Instruments
- AA alkaline batteries or rechargeable battery available
- Battery operation time more than 100 hours
- Low battery alarm
- Self-check function / Automatic power-off
- Large display (21 characters by 8 lines)
- Microprocessor-based field communicator
- USB port to charge
Specification
| Display | : | LCD dot matrix, 21 characters * 8 lines |
| Keypad | : | 20 General keys, one power switch |
| Signal Connection | : | Alligator clip or grabber clip |
| Cable Length | : | 1.5 m |
| Function | : | Display, setup and alteration of parameter |
| : | Zero point adjustment, calibration | |
| : | Auto power-off | |
| Communication Line | ||
| Line Length | : | Up to 1500 m |
| Load Resistance | : | 250-600 Ω |
| Load Capacitance | : | Less than 0.22 μF |
| Load Inductance | : | Less than 3.3 mH |
| Power Consumption | : | 191.3 mA (Working state) |
| : | 1 μA (Power-off state) | |
| Material | ||
| Case | : | ABS resin |
| Keyboard | : | Polycarbonate |
| Protection Class | : | IP54 |
| Operating Temperature | : | -20~55 °C |
| Storage Temperature | : | -20~55 °C |
| Ambient Humidity | : | 90% RH or less |
| Power | ||
| Battery | : | Three AA alkaline Batteries |
| : | Three Ni-MH Batteries (Rechargeable) | |
| Operable Time | : | Alkaline Battery: Up to 150 Hours |
| : | Ni-MH Battery: Up to 100 Hours | |
| Charge up time | : | Less than 12 hours |
| Dimensions | : | 231 mm (L) *102 mm (W) *61 mm (H) |
| Battery Charger | : | USB connect with computer |
| : | 90-260 VAC, 50/60 Hz | |
| Weight | : | 0.4 kg (Communicator) |
| : | 1 kg (Including accessories) | |
| Standard Package | ||
| : | ATH530 Hart Communicator * 1 set | |
| : | Communication cable 1.5 m * 1 pair | |
| : | USB connector 1.5 m (Charge) * 1 set | |
| : | Ni-MH Battery 1.2 V * 3 pcs | |
| : | Power Adapter 90-260 VAC * 1 set | |
| : | Alligator clip * 1 pair | |
| : | Grabber clip * 1 pair | |
| : | Shoulder bag * 1 set |
