ACF6000 Series
The ACF6000 Series uses the Coriolis effect as a technique for liquid mass flow measurement.
The ACF6000 can measure most of the liquids; the infrared light sensor makes it easy for you to set parameters & change the display data. The Double-C tube & Double-D Tube make it possible for the meter to be used in most liquid applications.
Features
- Can be programmed by infrared light sensor without opening cover
- High turndown ratio of flow rate
- It comes any flanges such as ANSI, DIN, JIS etc.
- Excellent for high pressure application
- Simple for installation, commission and maintenance
- Self-diagnostic capabilities, cable faults, pipe vibration
- High accuracy of +/-0.2% of reading (or +/-0.1% of reading)
- With forward / reverse flow rate measurement function
Specification
| Sensor Type | : | C tube(15-40 mm)/U tube(40L-250 mm) |
| Size | : | 15-250 mm (1/2″-10″) |
| Flow Range | : | 0-240 kg/hr~0-2200 t/hr |
| Accuracy | : | +/-0.2% +/-ZS of reading (Standard) |
| : | +/-0.1% +/-ZS of reading (Optional) | |
| Repeatability | : | +/-0.03% +/-ZS of reading |
| Density Range | : | 200-2300 kgf/m3 (0.2-2.3 g/cm3) |
| Accuracy | : | +/-0.002 g/cm3 |
| Temperature Range | : | -40~125 °C (Standard) |
| : | -40~350 °C (Optional, Remote Only) | |
| Material | ||
| Wetted Parts | : | Stainless Steel 316L |
| Flange | : | Stainless Steel 316L |
| Sensor Housing | : | Stainless Steel 304 |
| Junction Box | : | Aluminum Alloy (Epoxy Paint) |
| Process Connection | : | Flange |
| Flange Type | : | JIS 10K / JIS 20K / JIS 40K |
| : | ANSI 150# / ANSI 300# / ANSI 600# | |
| : | DIN PN10 / PN16 / PN25 / PN40 | |
| Protection Class | : | IP67 |
| : | Explosion Proof, Ex d e [ib] IIC T6 (Optional) | |
| Installation | : | Compact or Remote |
| Signal Cable Length | : | 10-100 m |
| Display | : | 2 lines LCD with illumination |
| Flow Rate Unit | : | g/s, kg/m, kg/hr, t/hr, lb/m, USgal/m (6 Digit) |
| Density Unit | : | kg/m3, g/cm3 (6 Digit) |
| Totalizer Unit | : | g, kg, Ton, L, m3, Nm3, lb, USgal (7 Digit) |
| Temperature | : | °C, °F (4 Digit) |
| Keypad | : | Infrared light Sensor, can be programmed |
| without opening the cover | ||
| Turndown Ratio | : | 20:1 |
| Damping | : | 0.01-1.0 Seconds |
| Low Flow Cutoff | : | 0.0-9.0% |
| Communication | : | RS485 (Modbus Protocol) (Standard) |
| : | HART Signal (Optional) | |
| Current Output | : | 4-20 mA (Isolated) |
| Load | : | Max. 750 Ω |
| Output Unit | : | Mass / Volume / Density / Temperature |
| Pulse Output | : | Open Collector |
| Rating | : | 3-30 VDC, 50 mA Max. |
| Alarm Output | : | Open Collector (Optional) |
| Power Supply | : | 90-260 VAC, 50/60 Hz or 24 VDC +/-10% |
| Power Consumption | : | 30-40 W (Depend on sensor size) |
| Cable Entry | : | Sensor to Converter-3/4″ G |
| : | Signal output / Power supply-M20 | |
| Ambient Temperature | : | -40~60 °C |
| Max. Pressure | : | 63 kgf/cm2 |
