AUF761 Series
The AUF761 Series is a fixed-mounted, transit-time ultrasonic Flowmeter. It features factory-mounted transducers that allow it to be flow lab calibrated, reducing or eliminating the random or bias error that can be present in clamp-on style transducer mounting. The meter ensures an accurate, non-invasive measurement of clean homogeneous liquid process, and is widely used in process control and production measurement.
Features
- 2 lines LCD display with flowrate, totalizer…
- Stores 720 Hours / 365 Days / 36 Months / 10 Years of Totalizer value
- Pipe size from DN20-DN1000 mm
- High accuracy of +/-1% of reading
- Bidirectional measurement
- Various output types such as 4-20 mA, pulse, RS485, Alarm
- With self-calibration function, real-time measurement calibration
- Accurate and stable measurement
- The sensor has anti-high temperature and long service life, It can reach to 200 °C in a short time
Specification
| Measuring Principle | : | Transit time difference |
| Pipe Size | : | DN20-DN1000 mm |
| Flow Velocity | : | 0.3 ~ +/-12 m/s |
| Resolution | : | 0.001 m/s |
| Accuracy | : | +/-1% of reading |
| Repeatability | : | +/-0.2% of reading |
| Response Time | : | Less than 1 second |
| Process Temperatue | : | -40~70 °C |
| : | -40~160 °C | |
| Max. Pressure | : | 100 kgf/cm2 |
| Process Connection | : | Thread (DN20-DN40) |
| : | Flange (DN20-DN1000) | |
| Flange Type | : | JIS 10K / JIS 20K / JIS 40K |
| ANSI 150# / ANSI 300# / ANSI 600# | ||
| DIN PN10 / PN16 / PN25 / PN40 | ||
| Body Material | : | S.S. 304 / S.S. 316 |
| Housing Material | : | Aluminum Alloy |
| Ambient Temperature | : | -20~50 °C |
| Protection Class | : | IP67 |
| Explosion Proof | : | Ex d IIC T4 |
| IR Remote Control | : | Intrinsically Safe, Ex ib IIC T6 |
| Keypad | : | 4 Internal Keys / IR Remote Control |
| Display | : | 2 Lines LCD with illumination |
| Flowrate | : | 7 Digit with decimal point |
| Totalizer | : | 8 Digit, Forward, Reverse & Net values. |
| Engineering Unit | : | m3, L, USgal, USbbl, ft3 |
| Time Unit | : | sec, min, hour, day |
| Other | : | Velocity, Date, Time, Signal condition |
| Max. Cable Length | : | 100 m |
| Power Consumption | : | Less than 2W |
| Power Supply | : | 90-260 VAC 50/60 Hz and 24 +/-10% VDC |
| Data Storage | : | Operation parameters and totalizer |
| figures are stored by EEPROM for | ||
| more than 10 years | ||
| Current Output | : | 4-20 mA |
| Load | : | Max. 800 Ω |
| Pulse Output | : | Scaled Pulse (Open Drain) |
| Rating | : | 3-35 VDC, 120 mA Max. |
| Alarm Output | : | 2 Relays, Upper and Lower alarm (Option) |
| Rating | : | 5A, 30 VDC / 5A, 250 VAC |
| Communication | : | RS485 (MODBUS) |
| Cable Entry | : | 1/2″ NPT (Female) (Standrad) |
| : | M20 * 1.5 (Option) |
