VEGAMET 841
Robust controller and display instrument for level sensors
For one 4 … 20 mA sensor
Application area
1 x 4 … 20 mA sensor input, 1 x 4 … 20 mA current output, 3 x operating relay, 1 x fail safe relay (instead of operating relay), on-site display, 4-button and smartphone operation
The VEGAMET 841 controller feeds the connected 4 … 20 mA sensor, processes the measured values and displays them. A large display for data visualisation is integrated in the housing designed for rough field conditions. It enables a simple conversion of pump controls, flow measurements on open channels and weirs and totalizers. With VEGAMET 841, limit values can be reliably monitored and relays can be switched, e.g. for an overfill protection according to WHG.
Your benefit
- Clearly arranged, readable from a distance and individually programmable display
- Complex programming of control tasks is no longer necessary
- Easy-to-read display from a distance, even in sunlight and darkness
Technical specifications
Protection rating
- IP66/IP67, Type 4X
Input
- 1 x 4 … 20 mA sensor input
Output
- 1 x 0/4 … 20 mA current output
- 3 x operating relay
- 1x failure relay (instead of operating relay)
Ambient temperature
- -40 … 60 °C
Approvals
Scope
- ATEX / Europe
- IEC / worldwide
- c-UL-us
- UKEX
Display & adjustment
Adjustment
- On-site adjustment
- Smartphone / Tablet / PC via Bluetooth
Indication
- LCD matrix display, black and white
- Backlight with colour change acc. to status
Documentation
