VEGAKON 61
Conductive limit switch for liquids for front-flush mounting
Compact level switch with partial PTFE insulation
Application area
For front-flush installation. The instrument is ideally suited as full or empty detector in pipelines.
The VEGAKON 61 is a condcutive limit switch for conductive liquids. The instrument is best suited as full and empty detector in pipelines.
Your benefit
- Optimum cleanability through front-flush mounting
- Maintenance-free operation through probe insensitive to buildup
- Time and cost-saving setup without adjustment with medium
Technical specifications
Measuring range – Distance
- – [Meter – Foot]
Process temperature
- -40 … 150 °C [°C – °F]
Process pressure
- -1 … 25 bar [Bar – kPa – psi]
Version
- Compact version
Materials, wetted parts
- PTFE
- 316L
Threaded connection
- G1
Hygenic fittings
- Cone DN25
Seal material
- no media contact
Housing material
- Plastic
Protection rating
- IP66
Output
- Relay (DPDT)
- Transistor (NPN/PNP)
Ambient temperature
- -40 … 70 °C
Documentation
Conductive
VEGAKON 61, VEGAKON 66, EL 1, 3, 4, 6, 8
VEGAKON 61
Relay (DPDT)
