VEGACAP 27
Adjustment-free, capacitive rod probe for level detection of adhesive products
Rod probe, fully PTFE or PFA insulated
Application area
For liquids, also in non-conductive containers, Sensor length up to 4 m
The VEGACAP 27 is an adjustment-free, capacitive level sensor for liquids. Typical applications are overfill and dry run protection for adhesive as well as conductive liquids. The probe operates in liquids with a dielectric constant from 1.5.
Your benefit
- Long lifetime and low maintenance requirement through robust mechanical construction
- Minimum time and cost expenditure thanks to simple setup without medium
- Exact switching point even with strong buildup
Technical specifications
Measuring range – Distance
- – [Meter – Foot]
Process temperature
- -50 … 200 °C [°C – °F]
Process pressure
- -1 … 63 bar [Bar – kPa – psi]
Version
- PTFE insulation
Materials, wetted parts
- PTFE
- 316Ti (1.4571)
- Steel
Threaded connection
- ≥ G1, ≥ 1 NPT
Hygenic fittings
- Clamp ≥ 2″, DN50 – DIN32676, ISO2852
- Clamp ≥ 1½” – DIN32676, ISO2852
- Slotted nut ≥ 2″, DN50 – DIN 11851
Seal material
- no media contact
Housing material
- Plastic
- Aluminium
Protection rating
- IP66/IP67
Output
- Relay (DPDT)
Ambient temperature
- -40 … 80 °C
Approvals
Overfill protection
- WHG
Display & adjustment
Adjustment
- Adjustment
Indication
- Indication
