Twin cylinders Series QX
Double-acting, magnetic, guided
Ø 10×2, 16×2, 20×2, 25×2, 32×2 mm
Ø 10×2, 16×2, 20×2, 25×2, 32×2 mm
Series QX actuators offer a wide range of solutions covering a great number of applications which require a guided linear movement.
The design of the double piston, besides assuring a solid and effective guide, offers double force in compact dimensions.
Where a high force with precise movement is required, along with a non-rotation function and integrated guide, the QX cylinders are the ideal solution.
The range includes two guide versions with sintered bronze bushes or with linear ball bearings.
General Data
| Type of construction | Compact, non magnetic QXT = sintered bronze bushes – QXB = linear ball bearings |
| Operation | Double-acting |
| Materials | Body and flange = anodized AL QXT piston rod = stainless steel AISI 303 – QXB piston rod = hardened steel C50 Seals = PU |
| Mounting method | By means of threaded holes |
| Strokes | From 10 to 100 |
| Operating temperature | 0° ÷ 80°C (with dry air – 20°C) |
| Operating speed | 50 ÷ 500 mm/s |
| Operating pressure | 1 ÷ 10 bar |
| Fluid | Clean air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted. |
Coding Example
| QX | T | 2 | A | 020 | A | 050 |
| QX | SERIES | |
| T | VERSION T = sintered bronze bushes B = linear ball bearings | |
| 2 | OPERATION 2 = double-acting (1 flange) radial/axial pressure supply (Ø10 on the side only) 3 = double-acting through-rod (double-flange), radial pressure supply | PNEUMATIC SYMBOLS CD15 CD16 |
| A | MATERIALS A = anodized aluminium body, rolled stainless steel AISI 303 (QXT) or hardened steel C50 (QXB) piston rod | |
| 020 | BORE 010 = 10 mm 016 = 16 mm 020 = 20 mm 025 = 25 mm 032 = 32 mm | |
| A | TYPE OF DESIGN A = standard | |
| 050 | STROKE (see the table) |
