S500 series_Rotary type Sight glass_S500, S510
Infomation
Rotary type sight glass allows visual monitoring of the internal fluid flow state as the fluid flows, causing the rotor to rotate.
Model : S500
| Connections | Screwed end Socket end |
| Max. pressure | 2.9 MPa |
| Max. temperature | 100 ℃ |
| Glass | Tempered |
| Body material | A216 WCB A351 CF8 A351 CF8M |
Model : S510
| Connections | Flanged end |
| Max. pressure | 2.9 MPa |
| Max. temperature | 300 ℃ |
| Glass | Tempered |
| Body material | A216 WCB A351 CF8 A351 CF8M A106 Gr.B |
