Pressure regulators Series N
Ports G1/8, G1/4
Series N pressure regulators are available with G1/4 and G1/8 ports.
Their design incorporates a self relieving diaphragm so as to allow decremental adjustments.
Their design incorporates a self relieving diaphragm so as to allow decremental adjustments.
General Data
<tbody “=””>
| Construction | Diaphragm type |
| Materials | Brass, technopolymer, NBR |
| Ports | G1/8 – G1/4 |
| Weight | 0,316 Kg |
| Pressure gauge ports | G1/8 |
| Mounting | In – line or console (in any position) |
| Working temperature | 0 ÷ 10 bar / -5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature) |
| Outlet pressure | 0,5 ÷ 10 bar (standard), 0,5 ÷ 2 bar; 0,5 ÷ 4 bar e 0,5 ÷ 7 bar |
| Secondary pressure (relieving) | With relieving (standard) Without relieving |
| Fluid | Compressed air |
Coding Example
| N | 12 | 04 | – | R | T | 0 | – |
| N | SERIES |
| 12 | SIZE 12 |
| 04 | PORTS 08 = G1/8 04 = G1/4 |
| R | REGULATOR |
| T | OPERATING PRESSURE 0 = 0,5 ÷ 10 bar (standard) 1 = 0,5 ÷ 4 bar 2 = 0,5 ÷ 2 bar 7 = 0,5 ÷ 7 bar T = Calibrated * B = Locked * |
| 0 | DESIGN TYPE 0 = Self-relieving 1 = Non-relieving |
* If the regulator is calibrated or locked, after the design type add the inlet pressure “■” and the outlet pressure “●
INLET PRESSURE:
■ = Enter the SUPPLY pressure value
OUTLET PRESSURE:
● = Enter the OUTLET pressure value for the LOCKED regulator or the maximum value of the ADJUSTABLE pressure for the CALIBRATED regulator
Example of a calibrated regulator with Inlet Pressure = 6,3 bar and Outlet Pressure = 4,5 bar
Complete part number: N1204-RT0-6,3-4,5
