Mechanically operated minivalves Series 2
3/2-way
Ports M5, cartridge Ø4
Ports M5, cartridge Ø4
Series 2 mechanically operated miniature valves, 3/2-way normally closed, are available with M5 threaded ports or with an integrated super-rapid fitting for Ø4mm tubes.
The devices are actuated by a plunger, roller/lever or a unidirectional lever.
The devices are actuated by a plunger, roller/lever or a unidirectional lever.
General Data
| Construction | Poppet type |
| Valve group | 3-way/2-position |
| Materials | Aluminium body, brass plunger, NBR seals |
| Mounting | By means of screws in the through-holes of the valve body |
| Ports | M5, Ø4mm cartridge |
| Room temperature | 0°C ÷ 60°C |
| Fluid temperature | 0°C ÷ 50°C |
| Operating pressure | 2 bar ÷ 10 bar |
| Fluid | Filtered air, without lubrication. If lubricated air is used, it is recommended to use ISO VG32 oil. Once applied the lubrication should never be interrupted. |
Coding Example
| 2 | 3 | 4 | – | 94 | 5 |
| 2 | SERIES |
| 3 | FUNCTION 3 = 3/2-way NC 4 = 3/2-way NO |
| 4 | PORTS 4 = Cartridge Ø4mm 5 = M5 |
| 94 | ACTUATION 94 = Plunger 95 = Lever/roller 96 = Unidirectional lever 98 = Plunger, panel mounting |
| 5 | RESETTING 5 = Spring return |
