Manually operated valves Series 1, 3, 4 and VMS
Series 1, 3 and 4: 3/2-, 5/2- and 5/3-way CC, CO; ports G1/8, G1/4
Series VMS: 3/2-way; ports M5, G1/8, G1/4, G3/8, G1/2 and G3/4
Series VMS: 3/2-way; ports M5, G1/8, G1/4, G3/8, G1/2 and G3/4
Series 3 manual valves (G1/8) and Series 4 (G1/4), 3/2-, 5/2- and 5/3-way, are available with several devices designed to satisfy different needs.
Series 1 is provided with two devices: pushbutton (3/2-way) and lever (3/2 and 5/2-way).
Series VMS valves are 3/2-way slide valves which are available with ports M5, G1/8, G1/4, G3/8, G1/2 and G3/4.
Series 1 is provided with two devices: pushbutton (3/2-way) and lever (3/2 and 5/2-way).
Series VMS valves are 3/2-way slide valves which are available with ports M5, G1/8, G1/4, G3/8, G1/2 and G3/4.
The 3/2-way valves Series 3 and 4 are normally closed when 1 is the inlet and they can also be normally open when 3 is the inlet.
Series 3 and 4 5/2-way valves can be supplied via ports 3 and 5 with two different pressures, if a cylinder has to be operated using a delivery pressure which is different from the return pressure.
General Data
| Construction | Series 3 and 4: spool-type Series 1: poppet-type Series VMS: slide |
| Function | Series 1, 3 and 4: 3/2 – 5/2 – 5/3 ways CC CO Series VMS: 3/2-way |
| Materials | Aluminium body, stainless steel spool, brass poppet, NBR seals |
| Ports | Series 1, 3 and 4: G1/8, G1/4 Series VMS: M5, G1/8, G1/4, G3/8, G1/2, G3/4 |
| Environmental temperature | 0°C ÷ 60°C |
| Medium temperature | 0°C ÷ 50°C |
| Operating pressure | See the single models |
| Fluid | Filtered air, without lubrication. If lubricated air is used, it is recommended to use ISO VG32 oil. Once applied the lubrication should never be interrupted. |
Coding Example
| 3 | 5 | 8 | – | 900 |
| 3 | SERIES 1 3 4 |
| 5 | FUNCTION 3 = 3/2-way NC 5 = 5/2-way 6 = 5/3-way CC 7 = 5/3-way CO 8 = 5/3-way CP |
| 8 | PORTS 8 = G1/8 4 = G1/4 |
| 900 | RESETTING 895 = Pushbutton, monostable, black 896 = Pushbutton, monostable, green 897 = Pushbutton, monostable, red 900 = Lever, bistable 905 = Lever, monostable 910 = Knob, bistable 915 = Knob, monostable 935 = Digital monostable 975 = Palm-switch, monostable, black 976 =Palm-switch, monostable, green 977 = Palm-switch, monostable, red 990 = Switch, bistable |
