JUMO IMAGO 500

The JUMO IMAGO 500 is a process and program controller with up to 8 controller channels or 4 program channels. The user interface masks can be adapted according to individual preferences. 2 screen masks allow user-specific placement of text, process values, background images, and icons

Category: Product list A-Z

Technical data
Downloads

Technical data

General technical data
Measuring inputs	Up to 8 user configurable analog inputs for: RTD temperature probes; resistance transmitters; thermocouples; current 0(4) to 20 mA; voltage 0(2) to 10 V; heater current, C-level control; customer-specific linearization possible
Digital inputs	6 digital inputs for potential-free contacts
Outputs	Max. 6 slots for the following plug-in cards: 2 relays (normally open contact); 1 relay (changeover contact); 2 logic outputs 0/5 V; 1 logic output 0/22 V; 1 solid state relay; 1 analog output; 1 voltage supply for two-wire transmitter via 22 V logic output
Additional contacts	Up to 2 external relay modules with 8 changeover contacts or 8 logic outputs 0/12 V
Interfaces/protocols	1 × RS422/485 (Modbus); 1 × PROFIBUS DP or RS422/485 (Modbus); setup interface
Number of control channels	Up to 8 independent and user configurable control channels
Controller structure	P; I; PD; PI; PID (2 sets of control parameters per channel)
Controller type	Two-state controller; three-state controller; modulating controller; continuous controller; continuous controller with integrated position controller
Program controller	50 programs each with up to 100 sections; max. total of 1000 sections, 16 control tracks
Alarms	16 limit value monitoring functions, each with 8 selectable alarm functions with timer and confirmation functions
Display	5-inch TFT color screen (320 × 420 pixels, 27 colors); plain text display available in English, German, French, and other languages; process-specific texts and screens individually configured; bar graph display
Mounting	Panel mounting
Protection type	At the front IP65; at the rear IP20
Voltage supply	AC 110 to 240 V +10/-15 %, 48 to 63 Hz; AC/DC 20 to 30 V, 48 to 63 Hz
Format	144 mm × 130 mm × 170 mm, installation dimensions 92 × 92 mm
Special features	Modular structure with plug-in cards that can be retrofitted individually; easy-to-use PC setup program including startup software; recording function with evaluation software; min. sampling rate 50 ms; autotuning procedure for determining the controller parameters; programmable operating level; math and logic functions; programmable function keys and individually configured process screen for plant visualization; teleservice and email notification (via external modem)
Approvals	cULus

General technical data

Measuring inputs

Up to 8 user configurable analog inputs for: RTD temperature probes; resistance transmitters; thermocouples; current 0(4) to 20 mA; voltage 0(2) to 10 V; heater current, C-level control; customer-specific linearization possible

Digital inputs

6 digital inputs for potential-free contacts

Outputs

Max. 6 slots for the following plug-in cards: 2 relays (normally open contact); 1 relay (changeover contact); 2 logic outputs 0/5 V; 1 logic output 0/22 V; 1 solid state relay; 1 analog output; 1 voltage supply for two-wire transmitter via 22 V logic output

Additional contacts

Up to 2 external relay modules with 8 changeover contacts or 8 logic outputs 0/12 V

Interfaces/protocols

1 × RS422/485 (Modbus); 1 × PROFIBUS DP or RS422/485 (Modbus); setup interface

Number of control channels

Up to 8 independent and user configurable control channels

Controller structure

P; I; PD; PI; PID (2 sets of control parameters per channel)

Controller type

Two-state controller; three-state controller; modulating controller; continuous controller; continuous controller with integrated position controller

Program controller

50 programs each with up to 100 sections; max. total of 1000 sections, 16 control tracks

Alarms

16 limit value monitoring functions, each with 8 selectable alarm functions with timer and confirmation functions

Display

5-inch TFT color screen (320 × 420 pixels, 27 colors); plain text display available in English, German, French, and other languages; process-specific texts and screens individually configured; bar graph display

Mounting

Panel mounting

Protection type

At the front IP65; at the rear IP20

Voltage supply

AC 110 to 240 V +10/-15 %, 48 to 63 Hz; AC/DC 20 to 30 V, 48 to 63 Hz

Format

144 mm × 130 mm × 170 mm, installation dimensions 92 × 92 mm

Special features

Modular structure with plug-in cards that can be retrofitted individually; easy-to-use PC setup program including startup software; recording function with evaluation software; min. sampling rate 50 ms; autotuning procedure for determining the controller parameters; programmable operating level; math and logic functions; programmable function keys and individually configured process screen for plant visualization; teleservice and email notification (via external modem)

Approvals

cULus
