Hygrostats

Hygrostats are primarily used as simple two-state controllers to control the relative humidity in conditioning cabinets and air ducts as well as to control air humidifiers and dehumidifiers in the building technology industry.

Categories: Humidity & CO2, Hygrostats

Technical data
Downloads

Technical data

General technical data
Measurement medium	Air, pressureless (non-aggressive)
Outputs	Switching output, floating changeover contact max. AC 250 V/15 A, depending on the version, also with double contact.
Measuring range	RH = 30 to 100 % RH
Application	Humidifying and dehumidifying, storerooms, cold-storage rooms, greenhouses, control cabinets
Version	Indoor and duct version
Protection type	IP20 indoor version, IP64 duct version
Sensing element	Hygrometric (water-resistant element)
Special features	Indoor version also suitable for flush-mounted box assembly, duct version can be used permanently in high humidity, mains voltage not required, sensing element largely maintenance-free, adjustment protection
Accessories	Holders, sun and rain protection, filter tubes

General technical data

Measurement medium

Air, pressureless (non-aggressive)

Outputs

Switching output, floating changeover contact max. AC 250 V/15 A, depending on the version, also with double contact.

Measuring range

RH = 30 to 100 % RH

Application

Humidifying and dehumidifying, storerooms, cold-storage rooms, greenhouses, control cabinets

Version

Indoor and duct version

Protection type

IP20 indoor version, IP64 duct version

Sensing element

Hygrometric (water-resistant element)

Special features

Indoor version also suitable for flush-mounted box assembly, duct version can be used permanently in high humidity, mains voltage not required, sensing element largely maintenance-free, adjustment protection

Accessories

Holders, sun and rain protection, filter tubes

Type
