EL 3
Conductive multiple rod electrode
Rod electrodes with PTFE insulation
Application area
With 2 to 5 rods, a corresponding number of switching points between 5 cm and 6 m can be realized. Extended temperature range through PTFE insulation. A VEGATOR 130 series controller is required for operation.
The multiple rod electrode EL 3 is a universal level switch for conductive liquids. The instrument is ideal as overfill and dry run protection or pump control in conjunction with VEGATOR 132 controllers.
Your benefit
- Simple setup with minimum time and cost expenditure
- High flexibility through shortenable probe
- Maintenance-free through robust design
Technical specifications
Measuring range – Distance
- – [Meter – Foot]
Process temperature
- -50 … 130 °C [°C – °F]
Process pressure
- -1 … 63 bar [Bar – kPa – psi]
Version
- with 2 rod electrodes
- with 3 rod electrodes
- with 4 rod electrodes
- with 5 rod electrodes
Materials, wetted parts
- PTFE
- 316Ti (1.4571)
- Alloy C4 (2.4610)
Threaded connection
- G1½
Seal material
- no media contact
Housing material
- Stainless steel (precision casting)
Protection rating
- IP66/IP67
Output
- For connection to a controller
Ambient temperature
- -40 … 80 °C
Approvals
Scope
- ATEX / Europe
- EAC (GOST) / Belarus
Explosion protection
- Intrinsic safety “i”
Overfill protection
- WHG
Documentation
Conductive
VEGAKON 61, VEGAKON 66, EL 1, 3, 4, 6, 8
