CAMLOGIC PFG05 Rotary paddle level switch
Rotary blade level switch for monitoring a level threshold, generally full or empty. For bulk solids in silos or bins. Sturdy construction with aluminum casing. Guaranteed reliability at an excellent quality price ratio. The ideal sensor for heavy-duty conditions and continuous cycles, even in atmospheres that are potentially explosive owing to the presence of dusts/powders. Conforms to the most recent ATEX standards.
Advantages
- Easy to install: specific tools or settings are not required.
- Provides the highest standard of safety in the presence of potentially explosive dusts/powders.
- Probe can be adapted to the material with a broad range of plastic or stainless steel blades.
- Mechanical and electrical customizing of the measuring instrument on request.
- Extremely reliable, the instrument can be used instead of radar, capacitive, ultrasound or continuous level probes as a safe signal.
Specifications
- Casing and cover in die-cast aluminium
- Shaft in AISI 303 / EN 1.4305 stainless steel on life-lubricated sealed bearings, with dust-tight retaining ring in NBR
- Broad range of paddles in polyamide or AISI 304 / EN 1.4301 stainless steel
- 2” 1/2 Gas (BSPP) process connection and M20x1,5 double cable entry
- Rotation speed 1 turn / minute
- Ambient temperature -20° to +70°C (-4° … +158°F)
– With low temperature optional -40° to +70°C (-40° … +158°F) - Process temperature -20° to +70°C (-4° … +158°F)
- Process pressure 0.8 to 5 bar (11.6 to 72,5 psi)
- IP65 protection rating (dust-tight, protection against water jets)
- Power consumption max 4 W
- Contact capacity 10A 250VAC / 0,5A 24VDC
- Micro switch SPDT output signal
If the product is to be used in areas with explosive atmospheres, the following characteristics apply:
- Process pressure 0.8 to 1.1 bar (11.6 to 15.9 psi)
