APT9600 Series
The MultiVariable Transmitter APT9600 Series is adaptable and capable of multivariable measurements of differential pressure, static pressure and process temperature. The Transmitter includes flow equations for steam, gases and liquids. This device is also engineered with built-in flow calculations for fully compensated mass flow measurements. Multivariable Transmitter designed to meet challenging processes.
Features
- Converter can be rotated in 4 directions for easy installation
- Multiple variable measures, streamline process and cost-efficiency
- Full compensation available for gas and steam measurements
- Liquid mass measurements can be density compensated by temperature
- 0.075% accuracy
- Parameter setting by keypad directly
- 4-20 mA output, HART communication
- Transmitter allows multivariable measurements in combinations of differential and static pressure and temperature
Specification
| Process Fluid | : | Liquid, Gas, Steam |
| Application | : | Differential pressure, Static pressure |
| Temperature, Flow | ||
| DP range | : | 0-200 kPa |
| Pressure Range | : | 0-25 MPa (0-250 bar) |
| Temperture | : | -25~500 °C (-13 °F ~ 932 °F) RTD (PT1000) |
| Flow Range | : | 0-999999 |
| Turndown Ratio | : | 100:1 |
| Accuracy | : | +/-0.075% of span |
| : | Class A (Temperature) | |
| Stability | : | +/-0.15% of URL for 2 years |
| Working Temperature | : | -25~95 °C |
| Ambient Temperature | : | -25~70 °C |
| Material | ||
| Flange / Adapter | : | Stainless Steel 304 / Stainless Steel 316 |
| Drains / Vents | : | Stainless Steel 304 / Stainless Steel 316 |
| Diaphragm | : | Stainless Steel 316L / Hastelloy C |
| Wetted O-Ring | : | Buna N / Viton / PTFE |
| Bolts & Nuts | : | Carbon Steel / Stainless Steel 316 |
| T. Sensor wetted parts | : | Stainless Steel 316L / Hastelloy C |
| Converter Housing | : | Low copper cast aluminum alloy with |
| polyurethane, light blue paint | ||
| Fill Fluid | : | Silicone Oil |
| Mounting | : | Direct Mounting/Bracket on 2″ Pipe |
| Display | : | 8-Digit totalizer, 6-Digit flow rate |
| : | 5-Digit Pressure, 5-Digit Temp. | |
| Display Unit | : | 32 Flow engineering unit |
| Keypad | : | 3 Internal keys for programming |
| and output setting | ||
| Current Output | : | 4-20 mA (2-Wire) |
| with HART signal (Compatible) | ||
| Load | : | Rohm= (VDC-12) * 50 |
| Power Supply | : | 12-32 VDC |
| Damping | : | 0-32 Seconds |
| Humidity Limit | : | 0-100% Relative Humidity |
| Turn on Time | : | 2 Seconds with minimum damping |
| Zero Calibration | : | Automatic zero calibration by press-button |
| Cable Entry | : | M20 Conduit Threads / 1/2″ NPT (Female) |
| Protection Class | : | IP67 (Standard) |
| : | Intrinsically Safe, Eex ia IIC T5 (Standard) | |
| : | Explosion Proof, Ex db IIC T6 | |
| EMI / RFI Effect | : | Follow SAMA PMC 33.1 from 20-1000 MHz |
| and for field strengths up to 30 V/m | ||
| Vibration Effect | : | +/-0.05% of URL per g to 200 Hz in any axis |
| Process Connection | : | 1/4″-18 NPT |
| : | 1/2″-14 NPT (with adapter) | |
| Dimensions | : | 102mm(W) * 188mm(H) * 130mm(D) |
| Weight | : | 3.5 kg |
