Adjustable overpressure exhaust valve Series VMR 1/8-B10
Ports: G1/8
The adjustable valve Mod. VMR 1/8-B10 allows to discharge the overpressure that can be generated in a volume.
General Data
| Valve group | Automatic valves |
| Construction | Diaphragm type |
| Materials | Brass body zinc-plated steel spring NBR seals |
| Mounting | In any position |
| Ports | G1/8 |
| Operating temperature | -5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature) |
| Medium | Filtered air, without lubrication. If lubricated air is used, it is recommended to use ISO VG32 oil. Once applied the lubrication should never be interrupted. |
