Activated carbon filters Series MX
MX2 ports: G3/8, G1/2, G3/4 – MX3 ports: G3/4, G1
Modular
Bowl with technopolymer cover and bayonet-type mounting
Modular
Bowl with technopolymer cover and bayonet-type mounting
MX is the new series of air treatment components realized by Camozzi, characterized by a modern, linear and compact design, offering high performances.
The perfect integration between metal alloys and technopolymers has allowed the realization of a reliable product, light and strong at the same time.
Thanks to a new concept of modularity, moreover, the mounting of components has become easier.
The perfect integration between metal alloys and technopolymers has allowed the realization of a reliable product, light and strong at the same time.
Thanks to a new concept of modularity, moreover, the mounting of components has become easier.
The Series MX has been realized to offer a multi-sector solution that guarantees saving in terms of installation time, space and costs.
General Data
| Construction | Modular, compact with activated carbon filtering element |
| Materials | See TABLE OF MATERIALS on the following page |
| Ports | MX2: G3/8 – G1/2 – G3/4 MX3: G3/4 – G1 |
| Mounting | Vertical in-line Wall-mounting (by means of clamps) |
| Working temperature | 10°C ÷ 40°C (t max = 60°C) |
| Quality of delivered air according to ISO 8573-1:2010 | Class [1:7:1] |
| Draining of condensate | No draining |
| Nominal flow | See FLOW DIAGRAMS on the following pages |
| Filtering element | Actived carbon |
| Residual oil content | < 0,003 mg/m³ |
| Fluid | Compressed air |
| Pre-filtering | It is recommended to use a filter with residual oil of 0,01mg/m³ |
Coding Example
| MX | 2 | – | 1/2 | – | FCA | 1 | – | LH |
| MX | SERIES |
| 2 | SIZE 2 = G3/8 – G1/2 – G3/4 3 = G3/4 – G1 |
| 1/2 | PORT 1/2 = G1/2 3/4 = G3/4 1 = G1 |
| FCA | ACTIVATED CARBON FILTER |
| 1 | VISUAL BLOCKAGE INDICATOR = Not present 1 = Present |
| LH | FLOW DIRECTION = From left to right (standard) LH = From right to left |
For the assembly of a single component with fixing flanges or wall-mounting, see the section “FRL Series MX Assembled”.
