Activated carbon filters Series MC
Ports: G1/4, G3/8 e G1/2
Modular
Metal bowl and bayonet-type mounting
Modular
Metal bowl and bayonet-type mounting
The activated carbon filters Serie MC are available with port G1/4, G3/8 and G1/2.
The bowls of these filters are made of metal with a transparent sight glass.
The bowls of these filters are made of metal with a transparent sight glass.
General Data
| Construction | Modular, compact with activated carbon filtering element | ||
| Materials | Zama, NBR, tecnopolymer, activated carbon | ||
| Ports | G1/4 | G3/8 | G1/2 |
| Weight | 0,342 Kg | 0,718 Kg | 0,688 Kg |
| Mounting | Vertical in line or wall-mounting | ||
| Working temperature | 10°C ÷ 40°C (t max = 60°C) | ||
| Quality of delivered air according to ISO 8573-1:2010 | Class [1:7:1] | ||
| Condensate drain | Not present | ||
| Working pressure | 0,3 ÷ 16 bar | ||
| Nominal flow | See FLOW DIAGRAMS on the following pages | ||
| Filtering element | Active carbon | ||
| Residual oil content | < 0,003 mg/m³ | ||
| Fluid | Compressed air | ||
| Pre-filtering | It is recommended to use a filter with residual oil of 0,01mg/m³ | ||
Coding Example
| MC | 2 | 02 | – | F | CA |
| MC | SERIES |
| 2 | SIZE 1 = G1/4 2 = G3/8 – G1/2 |
| 02 | PORTS 04 = G1/4 38 = G3/8 02 = G1/2 |
| F | FILTER |
| CA | CA = Actived carbon |
