A7100_Integral type thermowell
Service intended
A7100 is specially designed for use with the main piping and thermowell.
A7100 thermowell for temperature sensor is recommended for all process systems where pressure, velocity, viscous, abrasive, and corrosive materials are present individually or in combination.
A7100 is specially designed to be used for the situation where corrosive, contaminated, hot, and viscous pressure mediums are present, and it could be used for a chemical, food, beverage, biochemical, and pharmaceutical industry.
Standard features
| Special fetures | 3-A Grade High level of surface roughness Electropolised surface of wetted part (Special) |
| Gauge connection | G 3/8″(M) |
| Material | 316L SS |
| Working temperature | Process Temperature : – 50 to 200 ºC |
| Surface roughness of wetted part | Ra ≤ 0.25 µm Ra ≤ 0.25 µm with E.P (Special) |
