Main features
- Universal input configurable from the faceplate
- Accuracy better than 0,2% f.s. at nominal condition
- Deviation bargraph indication
Available resources
Brochure
– Brochure Controllers and programmers
– Gefran product range brochure
Documentation – Previous Versions
– Driver
User Manual
– Installation and Operation Manual
– GF_EXPRESS README
– GF_eXpress UserGuide
– GF_VEDO HL – Installations and Operation Manual
Datasheet
– 400-401 datasheet
Quick Start Guide
– 400-D-R-x (Heat & Alarm)
– 400-D-R-x (Heat & Cool)
– 400-R-R-x (Heat & Alarm)
– 400-R-R-x (Heat & Cool)
– 401-D-R-R-x
– 401-R-R-R-x
Configuration Software
– CATALOG VER. 3.2.0
– GF_EXPRESS VER 2.1.54
Certifications
– UK Conformity declaration – 400
– EAC CERTIFICATION
– EU_Conformity declaration_400, 401, 40T72, 450, 1000, 1001, 1101, 600, 600OF, 650, 1250, 1350, 1200, 1300, 800, 1600, 1800, 3400, 3500, 4400, 4500, 2301, 2500, MD8, GFXTERMO4
– UL Certification – UL – 1600 – 1800 – 40TB – 600 – 400 – 4A96 – 40A96 – 4F96
– UL Certifications – UL – 400/401 series
Technical specifications
Overview
Microprocessor controller, format 48×48 (1/16 DIN) menufactored using SMT.
The instruments provides a complete operator interface, protected by a Lexan® membrane that ensures level IP65 faceplate protection.
They have 4 keys, 4 digits display, 2 indicating LED’s for 400 model, 3 indicating LED’s for 401 model and a further 3 LED’s bar-graph.
The main input for the process variable is universal and provides the possibility to connect many types of input sensor:
- Thermocouple type J, K, R, S, T, B, E, N
- Resistance thermometer PT100 3-wires
- Thermistor PTC
- Linear inputs 0…60mV, 12…60mV, 0…20mA, 4…20mA, 0…10V, 2…10V
The type of input is selected from the faceplate keys and no external shunts or adapter are required.
Model 401 can have an auxiliary input for a 50mAac current transformer to monitor the load current.
It is also possible to set an alarm point related to the current transformer input in order to check eventual load malfunction.
The instruments have 2 (3 for 401 model) relay (5A/250Vac, cosφ=1) or static (10Vdc/30mA) outputs with Heat, Cool or Heat/Cool non sovrapposto and/or alarm function.
All the programming procedures of the instruments are facilitaded by the grouping of the parameters in function blocks (CFG for the control parameters, Inp for the inputs, Out for the outputs, etc.) and by the possibility of selecting a simplified menu for entering the most frequently used parameters.
To semplify the configuration even further, a programming kit is available for PC, which includes a menu driven configuration program for Windows and the necessary cable to connect the instrument (see technical data cod. 80021).
A configurable personal software protection code (password protection) can be used to restrict the levels of editing and displaying the configuration parameters.
