S300 Series_Ball type sight glass
Information
Sight glass with balls can check the fluid flow by observing motion of balls.
Model : S300
| Connections | Screwed end Socket ent |
| Max. pressure | 2.9 MPa |
| Max. temperature | 100 ℃ |
| Glass | Tempered |
| Body material | A216 WCB A351 CF8 A351 CF8M |
Model : S310
| Connections | Flanged end |
| Max. pressure | 2.9 MPa |
| Max. temperature | 100 ℃ |
| Glass | Tempered |
| Body material | A216 WCB A351 CF8 A351 CF8M A106 Gr.B |
