Rotary cylinders Series 30
Non magnetic, cushioned and not cushioned
ø 50, 63, 80, 100 mm
Rotational angles: 90° and 180°
ø 50, 63, 80, 100 mm
Rotational angles: 90° and 180°
Series 30 rotary cylinders are made of a special Aluminium profile.
Their compact dimensions and clean lines give a good aesthetic appearance.
A unique wear resistant guide block gives increased service life to the unit.
Their compact dimensions and clean lines give a good aesthetic appearance.
A unique wear resistant guide block gives increased service life to the unit.
Positioning gears are provided for the rotations.
On the heads there is a screw which allows rotation to be adjusted by ± 5°.
General Data
| Type of construction | Profile |
| Operation | Double acting |
| Materials | Aluminium profile body & end blocks – NBR seals – other parts – hardened steel |
| Mounting | By means of holes in body |
| Bore | ø 50, 63, 80, 100 mm |
| Installation | In any position |
| Working temperature | 0°C ÷ 50°C (- 20°C on dry air) |
| Standard rotation | 90° – 180° |
| Operating pressure | 0.5 ÷ 10 bar |
| Fluid | Clean air with or without lubrication |
Coding Example
| 30 | – | 050 | / | 090 | – | 3 |
| 30 | SERIES | PNEUMATIC SYMBOL CD17 |
| 050 | BORE 050 = 50 mm 063 = 63 mm 080 = 80 mm 100 = 100 mm | |
| 090 | ROTATIONAL ANGLES 090 = 90° 180 = 180° | |
| 3 | VERSION = cushioned 3 = not cushioned |
