Lubricators Series N
Ports G1/8, G1/4
Series N lubricators are available with G1/4 and G1/8 ports.
The special type of design allows a vast range of applications in relation to the amount of atomized oil and the air consumed.The body is made of brass, whilst the bowl can be in transparent PA12 or in nickelplated brass. The version with metal bowl is particularly suitable for applications subject to impacts or in the presence of aggressive agents that could damage the PA12 bowl.
The special type of design allows a vast range of applications in relation to the amount of atomized oil and the air consumed.The body is made of brass, whilst the bowl can be in transparent PA12 or in nickelplated brass. The version with metal bowl is particularly suitable for applications subject to impacts or in the presence of aggressive agents that could damage the PA12 bowl.
General Data
| Construction | Modular, compact |
| Materials | Brass, transparent PA12 or nickel-plated brass, NBR |
| Ports | G1/8 – G1/4 |
| Oil capacity | 26 cm³ (bowl size = 1) 37 cm³ (bowl size = 2) |
| Weight | 0,240 kg |
| Mounting | Vertical, inline |
| Working temperature | 1 ÷ 10 bar / -5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature) |
| Oil refilling | Without pressure |
| Oil for lubricator | Use ISO VG32 oils. Once applied, the lubrication should never be interrupted |
| Nominal flow | See FLOW DIAGRAMS on the following pages |
| Min. air consumption for lubrication | At 1 bar = 7.5 Nl/mi At 6 bar = 11 Nl/min |
| Fluid | Compressed air |
Coding Example
| N | 2 | 04 | – | L | 00 | – |
| N | SERIES |
| 2 | SIZE 1 = Small bowl (26 cm³) 2 = Normal bowl (37 cm³) |
| 04 | PORTS 08 = G1/8 04 = G1/4 |
| L | LUBRICATOR |
| 00 | DESIGN TYPE 00 = Atomized oil |
| BOWL MATERIAL = Transparent PA12 (standard) TM = Nickel-plated brass (only in the small size) |
